Indoor Unit Sizes 09K-12K (Front Panel) (continued)
noitartsullIerudecorP
5) Remove the screw (1) then remove the
electrical cover.
6) Disconnect the two connectors on the
display board.
7) Slide the front panel side to side to
release each axis.
8) Remove the screw (1) and rotate the
display board clockwise. Next, remove
the clips.
