Bryant 619PHA Series - Indoor Unit 09 K-12 K Occupancy Sensor Removal

50 Specifications subject to change without notice. SM619PHA-03
Indoor Unit Sizes 09K-12K (Occupancy Sensor)
NOTE: Remove the front panel and electrical parts (refer to the front panel, electrical parts, evaporator and fan motor
and fan removal steps) before disassembling the occupancy sensor.
noitartsullIerudecorP
1) Remove the screw (1), then remove the
Occupancy Sensor.
Occupancy Sensor
