56 Specifications subject to change without notice. SM619PHA-03
Indoor Unit Sizes 18K-24K (Front Panel) (continued)
noitartsullIerudecorP
12) Release the 5 hooks of the vertical
blades, then pull the vertical blades
toward the right and remove them.
13) Remove the display board’s screw (1).
14) Rotate the display board in the direction
shown in the picture (on the right).
