Bryant 619PHA Series - Indoor Unit 18 K-24 K Fan Motor and Fan Disassembly

SM619PHA-03 Specifications subject to change without notice. 63
Indoor Unit Sizes 18K-24K (Fan Motor and Fan)
NOTE: Remove the front panel, electrical parts and evaporator (refer to front panel, electrical parts, and evaporator
removal steps) before disassembling fan motor and fan.
noitartsullIerudecorP
1) Remove the screws (2) and remove the
fixing board of the fan motor.
2) Remove the bearing sleeve.
Screws
