64 Specifications subject to change without notice. SM619PHA-03
Indoor Unit Sizes 18K-24K (Fan Motor and Fan) (continued)
Indoor Unit Sizes 18K-24K (Step Motor)
NOTE: Remove the front panel and electrical parts (refer to the front panel, electrical parts removal steps) before
disassembling the step motor.
noitartsullIerudecorP
3) Remove the set screw.
4) Pull out the fan motor and fan assembly
from the side.
Fixing Screw
noitartsullIerudecorP
1) Remove the screws (2), then remove the
stepping motor.
Stepping Motor
