—10—
* Saturated suction leaving evaporator coil.
Sensible Heat Capacity (1000 Btuh)
Gross Cooling Capacity (1000 Btuh)
BF—Bypass Factor
NOTES:
1. Net capacities shown include a deduction for evaporator fan motor heat.
2. Contact manufacturer for cooling capacities at conditions other than
shown in table.
3. Formulas:
Leaving db = entering db —
Leaving wb = wb corresponding to enthalpy of air leaving coil (h
lwb
)
h
lwb
= h
ewb
—
where h
ewb
= enthalpy of air entering coil.
4. Direct interpolation is permissible. Do not extrapolate.
5. SHC is based on 80°F db temperature of air entering coil. Below 80°F
subtract (corr factor x CFM) from SHC.
Above 80°F db, add (corr factor x CFM) to SHC.
SHC CORRECTION FACTOR
Interpolation is permissible.
Correction Factor = 1.09 x (1 – BF) x (db – 80)
BYPASS
FACTOR
ENTERING AIR DRY-BULB TEMP (°F)
79 78 77 76 75 Under 75
81 82 83 84 85 Over 85
Correction Factor
0.10
0.20
0.30
0.98
0.87
0.76
1.96
1.74
1.53
2.94
2.62
2.29
3.92
3.49
3.05
4.91
4.36
3.82
Use formula
shown below
PERFORMANCE DATA Continued
ESTIMATED SOUND POWER LEVEL (dBA)*
* Estimated sound power levels have been derived using the method described in the 1987 ASHRAE Systems & Applications Handbook, chapter 52, p. 52.7.
CFM — Cubic Ft per Minute
ESP — External Static Pressure
RPM — Revolutions per Minute
UNIT
SIZE
CONDITIONS OCTAVE BAND CENTER FREQUENCY
CFM ESP 63 125 250 500 1000 2000 4000
FE4-002
400 0.25 63.0 59.0 55.0 52.0 50.0 48.0 44.0
600 0.25 64.7 60.7 56.7 53.7 51.7 49.7 45.7
800 0.25 66.0 62.0 58.0 55.0 53.0 51.0 47.0
1000 0.25 67.0 63.0 59.0 56.0 54.0 52.0 48.0
1200 0.25 67.8 63.8 59.8 56.8 54.8 52.8 48.8
1400 0.25 68.4 64.4 60.4 57.4 55.4 53.4 49.4
FE4-003
1400 0.25 63.0 59.0 55.0 52.0 50.0 48.0 44.0
1600 0.25 64.7 60.7 56.7 53.7 51.7 49.7 45.7
1800 0.25 66.0 62.0 58.0 55.0 53.0 51.0 47.0
1000 0.25 67.0 63.0 59.0 56.0 54.0 52.0 48.0
1200 0.25 67.8 63.8 59.8 56.8 54.8 52.8 48.8
1400 0.25 68.4 64.4 60.4 57.4 55.4 53.4 49.4
636 0.25 65.0 61.0 57.0 54.0 52.0 50.0 46.0
FE4-005
400 0.25 63.0 59.0 55.0 52.0 50.0 48.0 44.0
600 0.25 64.7 60.7 56.7 53.7 51.7 49.7 45.7
800 0.25 66.0 62.0 58.0 55.0 53.0 51.0 47.0
1000 0.25 67.0 63.0 59.0 56.0 54.0 52.0 48.0
1200 0.25 67.8 63.8 59.8 56.8 54.8 52.8 48.8
1400 0.25 68.4 64.4 60.4 57.4 55.4 53.4 49.4
1600 0.25 69.0 65.0 61.0 58.0 56.0 54.0 50.0
FE4-006
600 0.25 64.7 60.7 56.7 53.7 51.7 49.7 45.7
800 0.25 66.0 62.0 58.0 55.0 53.0 51.0 47.0
1000 0.25 67.0 63.0 59.0 56.0 54.0 52.0 48.0
1200 0.25 67.8 63.8 59.8 56.8 54.8 52.8 48.8
1400 0.25 68.4 64.4 60.4 57.4 55.4 53.4 49.4
1600 0.25 69.0 65.0 61.0 58.0 56.0 54.0 50.0
1800 0.25 69.5 65.5 61.5 58.5 56.5 54.5 50.5
2000 0.25 70.0 66.0 62.0 59.0 57.0 55.0 51.0
2150 0.25 70.3 66.3 62.3 59.3 57.3 55.3 51.3
sensible heat cap.
1.09 x CFM
total capacity (Btuh)
4.5 x CFM
