—11—
PERFORMANCE DATA Continued
AIRFLOW PERFORMANCE CORRECTION FACTORS
The FE4A Airflow Performance table was developed using fan coils with 10-kw electric heaters (2 elements) in the units. For fan coils
with heaters made up of a different number of elements, the external available static at a given CFM from the table may be corrected
by adding or subtracting pressure. Use table for correction.
FACTORY-INSTALLED FILTER STATIC PRESSURE DROP (In. wc)
AIR DELIVERY PERFORMANCE CORRECTION COMPONENT PRESSURE DROP (IN. WC)
AT INDICATED AIRFLOW (DRY TO WET COIL)
NOTE:
Subtract the above pressure drop corrections from unit airflow data when that component or condition is used. The remaining external static pressure
will be available for the duct system.
HEATER KW ELEMENTS
STATIC PRESSURE
CORRECTION (in. wc)
Sizes 002–005 Size 006
0 0 +.02 +.03
5 1 +.01 +.02
8, 10 2 0 0
9, 15 3 –.02 –.03
20 4 –.04 –.06
18, 24, 30 6 –.06 –.10
MODEL
FE4A
CFM
400 600 800 1000 1200 1400 1600 1800 2000
002 0.020 0.044 0.048 0.072 0.100 ————
003 — 0.020 0.035 0.051 0.070 0.092 ———
005 ——0.035 0.051 0.070 0.092 0.120 ——
006 ————0.070 0.092 0.120 0.152 0.187
MODEL
FE4A
CFM
600 700 800 900 1000 1100 1200 1300 1400 1500 1600
002 0.012 0.016 0.022 0.028 0.034 0.040 0.049 ——— —
003 — 0.026 0.034 0.042 0.052 0.063 0.075 0.083 0.091 0.098 0.110
005 — 0.006 0.008 0.010 0.012 0.015 0.017 0.020 0.023 0.027 0.030
CFM
1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100
006 0.013 0.016 0.018 0.020 0.023 0.027 0.030 0.034 0.039 0.044 0.048
