Ta b l e 1 —B a si c C on t r o l
MODE OPERATION DAMPER POSITION FAN SPEED
Off Off
Closed to outside
Off
Low Air exchange with outside Open to outside Low
High Air exchange with outside
Open to outside
High
Table 2—OneTouch Push Button Control
MODE OPERATION DAMPER POSITION FAN SPEED
Off Off
Closed to outside
Off
Low Air exchange with outside Open to outside Low
Intermittent Air exchange with outside
Open to outside
Low
High Air exchange with outside
Open to outside
High
Table 3—Standard Control
MODE DEHUMIDISTAT POSITION OPERATION
DAMPER
POSITION
FAN SPEED
ON
LED
AIR EXCHANGE
LED
Off Any Off
Closed to outside
Off Off Off
Low
Satisfied Air exchange with outside Open to outside Low On Off
Call for dehumidification Air exchange with outside
Open to outside
Low On On
Intermittent
Satisfied Air exchange with outside
Open to outside
High On Off
Call for dehumidification Air exchange with outside
Open to outside
High On On
Table 4—Automatic Control
MODE
DEHUMIDISTAT
POSITION
OPERATION
DAMPER
POSITION
FAN SPEED INDICATOR LEDS
Off Any Off Closed to outside Off Off
Intermittent
Satisfied
Air exchange with
outside
Open to outside Off Intermittent ON
Call for
dehumidification
Air exchange with
outside
Open to outside High
Intermittent and Exchange
ON
Continuous
Satisfied
Air exchange with
outside
Open to outside Low
Continuous and Exchange
ON
Call for
dehumidification
Air exchange with
outside
Open to outside High
Continuous and Exchange
ON
Recirculation
Satisfied Recirculation Closed to outside High Recirculation ON
Call for
dehumidification
Air exchange with
outside
Open to outside High
Recirculation and Exchange
ON
Any Any Any Any Maintenance (open door)
Table 5—Recommended Humidity Levels
OUTSIDE TEMPERATURE DOUBLE ---PANE WINDOWS TRIPLE---PANE WINDOWS
50° F 10° C
55 percent 65 percent
32° F 0° C
45 percent 55 percent
14° F --- 1 0 ° C
35 percent 45 percent
--- 4 ° F --- 2 0 ° C
30 percent 45 percent
-- 2 2 ° F -- 3 0 ° C
25 percent 35 percent
