Bryant LEGACY 213R User Manual

30
HEAT PUMP HEATING PERFORMANCE -- CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES deg F
--- 3 7 17 27 37 47 57 67
EDB CFM
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
213RNA048--A Outdoor Section With FC4DNF048 Indoor Section
65
1400 19.49 17.93 3.03 24.20 22.24 3.17 29.27 26.69 3.31 34.82 30.93 3.47 41.08 37.39 3.66 48.04 48.04 3.88 55.97 55.97 4.16 65.15 65.15 4.52
1600 19.80 18.21 3.05 24.54 22.55 3.18 29.60 26.99 3.30 35.23 31.29 3.45 41.58 37.83 3.62 48.63 48.63 3.83 56.69 56.69 4.10 64.63 64.63 4.28
1800 20.07 18.47 3.08 24.82 22.81 3.20 29.90 27.26 3.31 35.58 31.60 3.45 42.00 38.22 3.61 49.10 49.10 3.81 56.94 56.94 4.02 63.84 63.84 4.19
70
1400 18.95 17.43 3.15 23.75 21.82 3.31 28.85 26.30 3.46 34.34 30.50 3.63 40.51 36.87 3.83 47.41 47.41 4.07 55.18 55.18 4.36 64.26 64.26 4.73
1600 19.26 17.72 3.18 24.08 22.12 3.32 29.19 26.62 3.46 34.74 30.86 3.61 41.03 37.34 3.79 48.00 48.00 4.01 55.91 55.91 4.28 64.35 64.35 4.52
1800 19.54 17.98 3.21 24.37 22.39 3.34 29.50 26.89 3.47 35.10 31.17 3.61 41.45 37.72 3.78 48.48 48.48 3.98 56.46 56.46 4.25 63.91 63.91 4.41
75
1400 18.34 16.87 3.27 23.23 21.35 3.45 28.40 25.89 3.62 33.89 30.10 3.80 39.98 36.38 4.01 46.81 46.81 4.26 54.41 54.41 4.56 63.33 63.33 4.94
1600 18.66 17.17 3.30 23.57 21.66 3.46 28.75 26.22 3.61 34.27 30.44 3.78 40.45 36.81 3.97 47.37 47.37 4.20 55.14 55.14 4.47 63.98 63.98 4.79
1800 18.95 17.44 3.33 23.87 21.93 3.48 29.07 26.50 3.62 34.60 30.73 3.77 40.85 37.17 3.95 47.87 47.87 4.17 55.70 55.70 4.43 63.79 63.79 4.64
Heating Indoor Model Capacity Power Furnace Model
*FC4DN(F,B)048 1.00 1.00
FC4DN(F,B)048 1.01 1.01
FC4DN(F,B)060 1.01 0.99
FK4DNB006 0.99 0.98
FK4DNF005 0.99 1.02
CAR**4817A** 0.97 1.02 315(A,J)AV048090
CNRH*4821A** 0.99 1.05 315(A,J)AV048090
CNRH*6024A** 0.99 1.04 315(A,J)AV048090
CSRH*4812A** 0.99 1.04 315(A,J)AV048090
CSRH*6012A** 0.99 1.03 315(A,J)AV048090
CAR**4821A** 0.99 1.05 315(A,J)AV060110
CAR**6021A** 0.99 1.03 315(A,J)AV060110
CNRH*4821A** 0.99 1.04 315(A,J)AV060110
CNRH*6024A** 0.99 1.03 315(A,J)AV060110
CNRV*4821A** 0.99 1.04 315(A,J)AV060110
CSRH*4812A** 0.99 1.04 315(A,J)AV060110
CSRH*6012A** 0.99 1.02 315(A,J)AV060110
CAR**4824A** 0.99 1.04 315(A,J)AV066135
CAR**6024A** 0.99 1.02 315(A,J)AV066135
CNRH*4821A** 0.99 1.04 315(A,J)AV066135
CNRH*6024A** 0.99 1.02 315(A,J)AV066135
CNRV*4824A** 0.99 1.04 315(A,J)AV066135
CNRV*6024A** 0.99 1.02 315(A,J)AV066135
CSRH*4812A** 0.99 1.03 315(A,J)AV066135
CSRH*6012A** 0.99 1.01 315(A,J)AV066135
CAR**4824A** 0.99 1.03 315(A,J)AV066155
CAR**6024A** 0.99 1.02 315(A,J)AV066155
CNRH*4821A** 0.99 1.03 315(A,J)AV066155
CNRH*6024A** 0.99 1.02 315(A,J)AV066155
CNRV*4824A** 0.99 1.03 315(A,J)AV066155
CNRV*6024A** 0.99 1.02 315(A,J)AV066155
CSRH*4812A** 0.99 1.02 315(A,J)AV066155
CSRH*6012A** 0.99 1.00 315(A,J)AV066155
CAR**4821A** 0.99 1.06 355AAV060080
CAR**6021A** 1.00 1.05 355AAV060080
CNRH*4821A** 0.99 1.06 355AAV060080
CNRH*6024A** 0.99 1.05 355AAV060080
CNRV*4821A** 0.99 1.06 355AAV060080
CSRH*4812A** 0.99 1.05 355AAV060080
CSRH*6012A** 1.00 1.04 355AAV060080
CAR**4821A** 0.99 1.05 355AAV060100
CAR**6021A** 1.00 1.02 355AAV060100
CNRH*4821A** 0.99 1.05 355AAV060100
CNRH*6024A** 0.99 1.04 355AAV060100
CNRV*4821A** 0.99 1.05 355AAV060100
CSRH*4812A** 0.99 1.04 355AAV060100
CSRH*6012A** 1.00 1.04 355AAV060100
CAR**4824A** 0.99 1.05 355AAV060120
CAR**6024A** 0.99 1.04 355AAV060120
CNRH*4821A** 0.99 1.05 355AAV060120
CNRH*6024A** 0.99 1.04 355AAV060120
CNRV*4824A** 0.99 1.05 355AAV060120
CNRV*6024A** 0.99 1.04 355AAV060120
CSRH*4812A** 0.99 1.04 355AAV060120
CSRH*6012A** 0.99 1.03 355AAV060120
Seenoteonpg.31
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
