HEAT PUMP HEATING PERFORMANCE -- CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES deg F
--- 3 7 17 27 37 47 57 67
EDB CFM
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
213RNA060--- A Outdoor Section With FC4DNF060 Indoor Section
65
1750 25.42 23.39 3.96 30.92 28.42 4.10 36.95 33.69 4.27 43.61 38.73 4.45 51.09 46.49 4.67 59.02 59.02 4.84 66.24 66.24 5.05 65.65 65.65 5.01
2000 25.81 23.75 4.00 31.33 28.79 4.14 37.39 34.09 4.29 44.11 39.18 4.46 51.73 47.08 4.63 58.54 58.54 4.78 61.87 61.87 4.86 59.50 59.50 4.78
2250 26.18 24.08 4.06 31.71 29.14 4.18 37.79 34.46 4.33 44.55 39.57 4.48 51.85 47.18 4.61 57.18 57.18 4.74 58.08 58.08 4.75 55.04 55.04 4.67
70
1750 24.91 22.92 4.11 30.49 28.02 4.28 36.53 33.30 4.46 43.11 38.29 4.65 50.48 45.93 4.87 58.78 58.78 5.06 66.16 66.16 5.29 67.06 67.06 5.30
2000 25.31 23.28 4.16 30.90 28.39 4.31 36.97 33.71 4.47 43.61 38.73 4.65 51.10 46.50 4.86 58.50 58.50 5.00 63.00 63.00 5.12 61.80 61.80 5.07
2250 25.67 23.62 4.22 31.26 28.73 4.35 37.37 34.07 4.51 44.05 39.12 4.67 51.64 46.99 4.83 58.08 58.08 4.98 60.16 60.16 5.02 57.77 57.77 4.95
75
1750 24.36 22.41 4.27 30.00 27.57 4.45 36.07 32.89 4.64 42.61 37.85 4.85 49.92 45.43 5.08 58.19 58.19 5.31 66.02 66.02 5.54 68.87 68.87 5.63
2000 24.76 22.78 4.32 30.42 27.96 4.49 36.52 33.30 4.66 43.09 38.27 4.85 50.48 45.93 5.06 58.37 58.37 5.23 64.89 64.89 5.42 64.86 64.86 5.40
2250 25.13 23.12 4.38 30.81 28.31 4.53 36.93 33.67 4.69 43.54 38.67 4.87 51.04 46.44 5.06 58.07 58.07 5.20 61.75 61.75 5.29 60.03 60.03 5.24
Heating Indoor Model Capacity Power Furnace Model
*FC4DN(F,B)060 1.00 1.00
FK4DNB006 1.02 1.06
CAR**6024A** 1.00 1.03 315(A,J)AV066135
CSRH*6012A** 1.01 1.02 315(A,J)AV066135
CAR**6024A** 1.00 1.02 315(A,J)AV066155
CNRH*6024A** 1.01 1.04 315(A,J)AV066155
CNRV*6024A** 1.01 1.04 315(A,J)AV066155
CSRH*6012A** 1.01 1.01 315(A,J)AV066155
NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
* The Btuh heating capacity values shown are net integrated values from which the defrost effect has been subtracted. The Btuh heating from supplement
heaters should be added to those values to obtain total system capacity.
{ The kW values include the compressor, outdoor fan motor, and indoor blower motor. The kW from supplement heaters should be added to these values to
obtain total system kilowatts.
EDB — Entering Dry Bulb
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
