Bryant Legacy 215B Product Data

68
HEAT PUMP HEATING PERFORMANCE CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES ° F ( ° C)
--- 3 ( --- 1 9 . 4 ) 7 (---13.9) 17 ( ---8.3) 27 ( ---2.8) 37 (2.8) 47 (8.3) 57 (13.9) 67 (19.4)
EDB
°F (°C)
CFM
Capacity MBtuh
Tota l
Syst.
KW†
Capacity MBtuh
Tota l
Syst.
KW†
Capacity MBtuh
Tota l
Syst.
KW†
Capacity MBtuh
Tota l
Syst.
KW†
Capacity MBtuh
Tota l
Syst.
KW†
Capacity MBtuh
Tota l
Syst.
KW†
Capacity MBtuh
Tota l
Syst.
KW†
Capacity MBtuh
Tota l
Syst.
KW†
Tota l Integ* To ta l Integ* To t al Integ* Tot al Integ* Tot a l Integ* Tot a l Integ* Tota l Integ* Tota l Integ*
215BNA048****A Outdoor Section With FX4DNF049 Indoor Section
65
(18.3)
1400 16.57 15.24 2.69 21.81 20.04 2.81 27.40 24.99 2.93 34.27 30.44 3.11 40.13 36.52 3.25 46.61 46.61 3.41 54.13 54.13 3.58 62.36 62.36 3.76 1600 16.86 15.51 2.71 22.16 20.36 2.82 27.81 25.36 2.94 34.67 30.79 3.10 40.59 36.94 3.22 47.18 47.18 3.37 54.95 54.95 3.50 62.79 62.79 3.67 1800 17.12 15.75 2.74 22.46 20.64 2.85 28.17 25.69 2.95 34.99 31.07 3.10 40.98 37.29 3.21 47.66 47.66 3.34 55.35 55.35 3.45 63.02 63.02 3.60
70
(21.1)
1400 15.87 14.60 2.80 21.11 19.40 2.92 26.66 24.31 3.05 33.71 29.94 3.24 39.54 35.98 3.39 45.93 45.93 3.56 53.20 53.20 3.76 61.54 61.54 3.94 1600 16.17 14.88 2.82 21.47 19.73 2.93 27.09 24.70 3.06 34.13 30.31 3.23 40.02 36.42 3.37 46.50 46.50 3.52 54.09 54.09 3.66 62.01 62.01 3.84 1800 16.43 15.12 2.85 21.77 20.01 2.96 27.45 25.03 3.07 34.48 30.63 3.23 40.41 36.77 3.36 46.98 46.98 3.49 54.63 54.63 3.61 62.29 62.29 3.78
75
(23.9)
1400 15.12 13.91 2.92 20.36 18.71 3.04 25.89 23.61 3.18 32.01 28.43 3.34 38.98 35.48 3.54 45.26 45.26 3.72 52.30 52.30 3.93 60.68 60.68 4.11 1600 15.41 14.18 2.94 20.72 19.04 3.06 26.32 24.00 3.18 32.64 28.99 3.33 39.43 35.88 3.51 45.81 45.81 3.67 53.21 53.21 3.84 61.21 61.21 4.02 1800 15.68 14.43 2.97 21.03 19.32 3.08 26.68 24.32 3.20 33.89 30.10 3.36 39.81 36.23 3.50 46.28 46.28 3.65 53.84 53.84 3.78 61.52 61.52 3.95
HEATING IN DOOR
MODEL
CAPACITY POWER FURN ACE MODEL
*FX4DN(B,F)049 1.00 1.00
FB4CNF048 0.99 1.03 FB4CNF060 0.99 1.00
FE4AN(B,F)005 0.97 0.99
FE4ANB006 0.98 0.97
FV4BN(B,F)005 0.97 0.99
FV4BNB006 0.98 0.97
FV4CN(B,F)005 0.97 0.99
FV4CNB006 0.98 0.97
FX4CN(B,F)048 0.99 1.00 FX4CN(B,F)060 1.00 0.98 FX4DN(B,F)061 0.99 0.96
FY4ANB060 1.01 1.04
FY4ANF048 1.00 1.06
FY5BNB060 1.01 1.04
FY5BNF048 0.99 1.01
CAP**4817A** 0.99 1.04 CAP**4821A** 1.00 1.05 CAP**4823A** 1.00 1.05 CAP**4824A** 1.00 1.05 CAP**6021A** 1.00 1.03 CAP**6024A** 1.00 1.03 CAP**6025A** 1.00 1.03
CNPF*4818A** 0.98 1.06
CNPH*4821A** 1.00 1.05 CNPH*6024A** 1.00 1.04 CNPH*6124A** 1.01 1.02
CNPV*4821A** 1.00 1.05 CNPV*4824A** 1.00 1.05 CNPV*6024A** 1.00 1.04 CNPV*6124A** 1.01 1.02
CSPH*4812A** 1.00 1.03 CSPH*6012A** 1.00 1.02
CAP**4817A** 0.98 1.02 315(A,J)AV048090
CNPH*4821A** 0.97 1.02 315(A,J)AV048090 CNPH*6024A** 0.97 1.00 315(A,J)AV048090 CNPH*6124A** 0.98 1.00 315(A,J)AV048090
CSPH*4812A** 0.98 1.02 315(A,J)AV048090 CSPH*6012A** 0.98 1.01 315(A,J)AV048090
CAP**4821A** 0.97 1.02 315(A,J)AV060110
HEATING IN DOOR
MODEL
CAPACITY POWER FURN ACE MODEL
CAP**6021A** 0.98 1.01 315(A,J)AV060110
CNPH*4821A** 0.97 1.01 315(A,J)AV060110 CNPH*6024A** 0.97 1.00 315(A,J)AV060110 CNPH*6124A** 0.98 1.00 315(A,J)AV060110
CNPV*4821A** 0.97 1.01 315(A,J)AV060110 CNPV*6124A** 0.98 0.99 315(A,J)AV060110
CSPH*4812A** 0.98 1.02 315(A,J)AV060110 CSPH*6012A** 0.98 1.00 315(A,J)AV060110
CAP**4824A** 0.97 1.00 315(A,J)AV066135 CAP**6024A** 0.97 0.99 315(A,J)AV066135
CNPH*4821A** 0.97 1.00 315(A,J)AV066135 CNPH*6024A** 0.97 0.99 315(A,J)AV066135 CNPH*6124A** 0.98 0.99 315(A,J)AV066135
CNPV*4824A** 0.97 1.00 315(A,J)AV066135 CNPV*6024A** 0.97 0.99 315(A,J)AV066135 CNPV*6124A** 0.98 0.98 315(A,J)AV066135
CSPH*4812A** 0.97 1.00 315(A,J)AV066135 CSPH*6012A** 0.97 0.98 315(A,J)AV066135
CAP**4824A** 0.97 1.00 315(A,J)AV066155 CAP**6024A** 0.97 0.98 315(A,J)AV066155
CNPH*4821A** 0.97 0.99 315(A,J)AV066155 CNPH*6024A** 0.97 0.98 315(A,J)AV066155 CNPH*6124A** 0.98 0.98 315(A,J)AV066155
CNPV*4824A** 0.97 0.99 315(A,J)AV066155 CNPV*6024A** 0.97 0.98 315(A,J)AV066155 CNPV*6124A** 0.98 0.97 315(A,J)AV066155
CSPH*4812A** 0.97 0.99 315(A,J)AV066155 CSPH*6012A** 0.97 0.97 315(A,J)AV066155
CAP**4823A** 0.99 1.04 359BAV060080 CAP**6025A** 0.98 1.01 359BAV060100 CAP**4817A** 0.99 1.03 353(A,B)AV048080
CNPH*4821A** 0.98 1.02 353(A,B)AV048080 CNPH*6024A** 0.99 1.02 353(A,B)AV048080 CNPH*6124A** 0.99 1.00 353(A,B)AV048080
CSPH*4812A** 0.99 1.03 353(A,B)AV048080 CSPH*6012A** 0.99 1.01 353(A,B)AV048080
CAP**4821A** 0.97 1.01 353(A,B)AV060100 CAP**6021A** 0.98 1.00 353(A,B)AV060100
CNPH*4821A** 0.97 1.00 353(A,B)AV060100 CNPH*6024A** 0.98 0.99 353(A,B)AV060100
HEATING IN DOOR
MODEL
CAPACITY POWER FURN ACE MODEL
CNPH*6124A** 0.98 0.98 353(A,B)AV060100
CNPV*4821A** 0.97 1.00 353(A,B)AV060100
CSPH*4812A** 0.98 1.00 353(A,B)AV060100 CSPH*6012A** 0.98 0.98 353(A,B)AV060100
CAP**4824A** 0.97 0.99 353(A,B)AV060120 CAP**6024A** 0.98 0.99 353(A,B)AV060120
CNPH*4821A** 0.97 0.99 353(A,B)AV060120 CNPH*6024A** 0.98 0.99 353(A,B)AV060120 CNPH*6124A** 0.98 0.97 353(A,B)AV060120
CNPV*4824A** 0.97 0.99 353(A,B)AV060120 CNPV*6024A** 0.98 0.99 353(A,B)AV060120 CNPV*6124A** 0.98 0.96 353(A,B)AV060120
CSPH*4812A** 0.98 1.00 353(A,B)AV060120 CSPH*6012A** 0.98 0.98 353(A,B)AV060120
CAP**4821A** 0.97 1.03 355(A,C)AV060080 CAP**6021A** 0.98 1.03 355(A,C)AV060080
CNPH*4821A** 0.97 1.03 355(A,C)AV060080 CNPH*6024A** 0.97 1.02 355(A,C)AV060080 CNPH*6124A** 0.98 1.02 355(A,C)AV060080
CNPV*4821A** 0.97 1.03 355(A,C)AV060080
CSPH*4812A** 0.98 1.03 355(A,C)AV060080 CSPH*6012A** 0.98 1.02 355(A,C)AV060080
CAP**4821A** 0.98 1.04 355(A,C)AV060100 CAP**6021A** 0.98 1.02 355(A,C)AV060100
CNPH*4821A** 0.98 1.03 355(A,C)AV060100 CNPH*6024A** 0.98 1.02 355(A,C)AV060100 CNPH*6124A** 0.99 1.01 355(A,C)AV060100
CNPV*4821A** 0.98 1.03 355(A,C)AV060100 CNPV*6124A** 0.99 1.00 355(A,C)AV060100
CSPH*4812A** 0.98 1.02 355(A,C)AV060100 CSPH*6012A** 0.98 1.01 355(A,C)AV060100
CAP**4824A** 0.97 1.01 355(A,C)AV060120 CAP**6024A** 0.98 1.01 355(A,C)AV060120
CNPH*4821A** 0.97 1.01 355(A,C)AV060120 CNPH*6024A** 0.98 1.01 355(A,C)AV060120 CNPH*6124A** 0.98 1.00 355(A,C)AV060120
CNPV*4824A** 0.97 1.01 355(A,C)AV060120 CNPV*6024A** 0.98 1.01 355(A,C)AV060120 CNPV*6124A** 0.98 0.99 355(A,C)AV060120
CSPH*4812A** 0.98 1.02 355(A,C)AV060120
