HEAT PUMP HEATING PERFORMANCE CONTINUED

INDOOR AIR

OUTDOOR COIL ENTERING AIR TEMPERATURES ° F ( ° C)

--- 3 ( --- 1 9 . 4 ) 7 (---13.9) 17 ( ---8.3) 27 ( ---2.8) 37 (2.8) 47 (8.3) 57 (13.9) 67 (19.4)

EDB

°F (°C)

CFM

Capacity MBtuh

Tota l

Syst.

KW†

Capacity MBtuh

Tota l

Syst.

KW†

Capacity MBtuh

Tota l

Syst.

KW†

Capacity MBtuh

Tota l

Syst.

KW†

Capacity MBtuh

Tota l

Syst.

KW†

Capacity MBtuh

Tota l

Syst.

KW†

Capacity MBtuh

Tota l

Syst.

KW†

Capacity MBtuh

Tota l

Syst.

KW†

Tota l Integ* To ta l Integ* To t al Integ* Tot al Integ* Tot a l Integ* Tot a l Integ* Tota l Integ* Tota l Integ*

215BNA060****A Outdoor Section With FX4DNF061 Indoor Section

(18.3)

1750 20.70 19.04 3.28 27.02 24.83 3.42 33.72 30.75 3.56 41.23 36.62 3.72 49.82 45.33 3.93 57.86 57.86 4.12 67.41 67.41 4.34 78.26 78.26 4.58

2000 21.11 19.43 3.32 27.50 25.28 3.45 34.30 31.27 3.58 42.09 37.39 3.72 50.38 45.85 3.90 58.60 58.60 4.07 68.57 68.57 4.25 79.11 79.11 4.49

2250 21.49 19.77 3.37 27.92 25.66 3.49 34.77 31.71 3.60 43.47 38.61 3.77 50.91 46.33 3.90 59.23 59.23 4.06 69.29 69.29 4.21 79.67 79.67 4.43

(21.1)

1750 19.65 18.07 3.42 26.01 23.91 3.57 32.79 29.90 3.72 40.18 35.69 3.88 49.10 44.68 4.11 57.00 57.00 4.30 66.31 66.31 4.55 77.15 77.15 4.78

2000 20.06 18.45 3.46 26.49 24.34 3.59 33.34 30.39 3.73 40.83 36.26 3.88 49.67 45.20 4.08 57.72 57.72 4.26 67.32 67.32 4.46 78.01 78.01 4.68

2250 20.43 18.80 3.50 26.91 24.73 3.63 33.81 30.82 3.76 41.39 36.76 3.89 50.19 45.68 4.08 58.34 58.34 4.24 68.30 68.30 4.40 78.62 78.62 4.63

(23.9)

1750 18.54 17.06 3.56 24.96 22.94 3.72 31.79 28.98 3.88 39.14 34.76 4.06 48.41 44.05 4.30 56.16 56.16 4.50 65.21 65.21 4.76 76.04 76.04 4.99

2000 18.95 17.44 3.60 25.43 23.37 3.75 32.33 29.47 3.90 39.76 35.31 4.05 49.00 44.59 4.27 56.88 56.88 4.45 66.27 66.27 4.66 76.93 76.93 4.89

2250 19.32 17.77 3.65 25.85 23.76 3.79 32.79 29.90 3.92 40.31 35.80 4.06 49.45 45.00 4.26 57.47 57.47 4.43 67.20 67.20 4.61 77.54 77.54 4.83

HEATING IN DOOR

MODEL

CAPACITY POWER FURN ACE MODEL

*FX4DN(B,F)061 1.00 1.00

FB4CNF060 0.98 1.03

FE4ANB006 0.98 0.98

FV4BNB006 0.98 0.98

FV4CNB006 0.98 0.98

FX4CN(B,F)060 0.98 0.99

FY4ANB060 1.00 1.05

FY5BNB060 1.02 1.07

CAP**6021A** 0.99 1.04

CAP**6024A** 0.99 1.04

CAP**6025A** 0.99 1.04

CNPH*6024A** 0.99 1.04

CNPH*6124A** 0.99 1.03

CNPV*6024A** 0.99 1.04

CNPV*6124A** 0.99 1.02

CSPH*6012A** 0.99 1.03

CAP**6021A** 0.99 1.04 315(A,J)AV060110

CNPH*6024A** 0.99 1.04 315(A,J)AV060110

CNPH*6124A** 0.99 1.03 315(A,J)AV060110

CSPH*6012A** 0.99 1.03 315(A,J)AV060110

CAP**6024A** 0.99 1.03 315(A,J)AV066135

CNPH*6024A** 0.99 1.03 315(A,J)AV066135

CNPH*6124A** 0.99 1.02 315(A,J)AV066135

CNPV*6024A** 0.99 1.03 315(A,J)AV066135

CNPV*6124A** 0.99 1.00 315(A,J)AV066135

CSPH*6012A** 0.99 1.02 315(A,J)AV066135

CAP**6024A** 0.99 1.02 315(A,J)AV066155

CNPH*6024A** 0.99 1.02 315(A,J)AV066155

CNPH*6124A** 0.99 1.01 315(A,J)AV066155

CNPV*6024A** 0.99 1.02 315(A,J)AV066155

HEATING IN DOOR

MODEL

CAPACITY POWER FURN ACE MODEL

CNPV*6124A** 0.99 1.00 315(A,J)AV066155

CSPH*6012A** 0.99 1.01 315(A,J)AV066155

CAP**6025A** 1.02 1.08 359BAV060100

CNPH*6024A** 0.99 1.06 353(A,B)AV048080

CSPH*6012A** 0.99 1.05 353(A,B)AV048080

CAP**6021A** 0.99 1.04 353(A,B)AV060100

CNPH*6024A** 0.99 1.04 353(A,B)AV060100

CNPH*6124A** 0.99 1.03 353(A,B)AV060100

CSPH*6012A** 0.99 1.02 353(A,B)AV060100

CAP**6024A** 0.99 1.03 353(A,B)AV060120

CNPH*6024A** 0.99 1.03 353(A,B)AV060120

CNPH*6124A** 0.99 1.02 353(A,B)AV060120

CNPV*6024A** 0.99 1.03 353(A,B)AV060120

CNPV*6124A** 0.99 1.00 353(A,B)AV060120

CSPH*6012A** 0.99 1.02 353(A,B)AV060120

CNPV*6124A** 0.99 1.02 355(A,C)AV060120

CSPH*6012A** 0.99 1.04 355(A,C)AV060120

CAP**6021A** 0.99 1.03 313*AV060110

CNPH*6024A** 0.99 1.03 313*AV060110

CNPH*6124A** 0.99 1.02 313*AV060110

CSPH*6012A** 0.99 1.01 313*AV060110

CAP**6024A** 0.99 1.04 313*AV060135

CNPH*6024A** 0.99 1.04 313*AV060135

CNPH*6124A** 0.99 1.03 313*AV060135

CNPV*6024A** 0.99 1.04 313*AV060135

CNPV*6124A** 0.99 1.01 313*AV060135

CSPH*6012A** 0.99 1.02 313*AV060135

CAP**6024A** 1.00 1.05 925*A66120E24***

CAP**6025A** 1.00 1.05 925*A66120E24***

HEATING IN DOOR

MODEL

CAPACITY POWER FURN ACE MODEL

CSPH*6012A** 1.00 1.04 925* A66120E24***

CNPV*6124A** 1.01 1.04 925* A66120E24***

CNPV*6024A** 1.00 1.05 925* A66120E24***

CNPH*6024A** 1.00 1.05 925* A66120E24***

CNPH*6124A** 1.00 1.04 925* A66120E24***

CAP**6024A** 1.01 1.06 986*A66120V24***

CAP**6025A** 1.01 1.06 986*A66120V24***

CSPH*6012A** 1.01 1.05 986* A66120V24***

CNPV*6124A** 1.00 1.03 986* A66120V24***

CNPV*6024A** 1.01 1.06 986* A66120V24***

CNPH*6024A** 1.01 1.06 986* A66120V24***

CNPH*6124A** 1.00 1.04 986* A66120V24***

CAP**6021A** 1.01 1.09 987*A60100V21***

CAP**6024A** 1.01 1.08 987*A60100V21***

CAP**6025A** 1.01 1.08 987*A60100V21***

CSPH*6012A** 1.01 1.07 987* A60100V21***

CNPV*6124A** 1.01 1.06 987* A60100V21***

CNPV*6024A** 1.00 1.08 987* A60100V21***

CNPH*6024A** 1.00 1.08 987* A60100V21***

CNPH*6124A** 1.01 1.08 987* A60100V21***

CAP**6024A** 1.00 1.05 987*A66120V24***

CAP**6025A** 1.00 1.05 987*A66120V24***

CSPH*6012A** 1.00 1.04 987* A66120V24***

CNPV*6124A** 1.00 1.03 987* A66120V24***

CNPV*6024A** 1.00 1.05 987* A66120V24***

CNPH*6024A** 1.00 1.05 987* A66120V24***

CNPH*6124A** 1.00 1.04 987* A66120V24***

NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.

* The Btuh heatin g capacity values shown are net integrated values from which the defrost effect has been subtracted. The Btuh heating from supplement heaters should be added to those values to obtain total system capacity.

{ Th e kW values include the compressor, outdoor fan motor, an d indoor blower motor. Th e kW from supplement heaters should be added to these values to obtain total system kilowatts.

EDB —EnteringDryBulb

215B
