Bryant Legacy Series Installation, Start-Up And Service Instructions

18
Table 14 — 569J*07-14A/B/G/H Electrical Data without Powered Convenience Outlet
Table 15 — 569J*07-14A/B/G/H Electrical Data with Powered Convenience Outlet
LEGEND
See Notes for Tables 14-17 on page 19.
UNIT
SIZE
TWO
STAGE
COOLING
V-Ph-Hz
VOLTAGE RANGE
COMPRESSOR
OFM POWER SUPPLY DISCONNECT SIZE
NO. 1
Min Max RLA LRA Qty FLA (ea) MCA
Fuse or
HACR
Breaker
FLA LRA
07
YES 575-3-60 518 633 6.3 55 2 0.7 10 15 9 59
YES 208/230-3-60 187 253 17.5 136 2 1.5 25/25 30/30 24/24 142/142
YES 460-3-60 414 506 8.4 66 2 0.8 13 20 12 70
NO 575-3-60 518 633 6.6 55 2 0.7 10 15 9 59
NO 208/230-3-60 187 253 19.6 136 2 1.5 28/28 45/45 26/26 142/142
NO 460-3-60 414 506 8.2 66 2 0.8 12 20 11 70
08
YES 575-3-60 518 633 9.9 78 2 0.7 14 20 13 82
YES 208/230-3-60 187 253 26.8 164 2 1.5 37/37 60/60 34/34 170/170
YES 460-3-60 414 506 12.6 100 2 0.8 18 25 16 104
NO 575-3-60 518 633 9.0 78 2 0.7 13 20 12 82
NO 208/230-3-60 187 253 25.0 164 2 1.5 35/35 50/50 32/32 170/170
NO 460-3-60 414 506 12.2 100 2 0.8 17 25 16 104
12
NO 575-3-60 518 633 11.3 94 2 0.7 16 25 15 98
NO 208/230-3-60 18725328.2 239 2 1.5 39/39 60/60 36/36 245/245
NO 460-3-60 414 506 14.7 130 2 0.8 20 30 19 134
14
NO 575-3-60 518
633 14.7 100 2 0.7 20 30 19 104
NO 208/230-3-60 18725348.1 245 2 1.5 64/64 80/80 59/59 251/251
NO 460-3-60 414 506 18.6 125 2 0.8 25 30 23 129
UNIT
SIZE
TWO
STAGE
COOLING
NOMINAL
POWER
SUPPLY
VOLTAGE RANGE
COMPRESSOR
OFM POWER SUPPLY DISCONNECT SIZE
NO. 1
Volts Min Max RLA LRA Qty FLA (ea) MCA
Fuse or
HACR
Breaker
FLA LRA
07
YES 575-3-60 518 633 6.3 55 2 0.7 11 15 11 61
YES 208/230-3-60 187 253 17.5 136 2 1.5 30/30 45/45 29/29 147/147
YES 460-3-60 414 506 8.4 66 2 0.8 15 20 14 72
NO 575-3-60 518 633 6.6 55 2 0.7 12 15 11 61
NO 208/230-3-60 187 253 19.6 136 2 1.5 33/33 50/50 32/32 147/147
NO 460-3-60 414 506 8.2 66 2 0.8 15 20 14 72
08
YES 575-3-60 518 633 9.9 78 2 0.7 16 25 15 84
YES 208/230-3-60 187 253 26.8 164 2 1.5 42/42 60/60 40/40 175/175
YES 460-3-60 414 506 12.6 100 2 0.8 20 30 19 106
NO 575-3-60 518 633 9.0 78 2 0.7 15 20 14 84
NO 208/230-3-60 187 253 25.0 164 2 1.5 40/40 60/60 38/38 175/175
NO 460-3-60 414 506 12.2 100 2 0.8 20 30 18 106
12
NO 575-3-60 518 633 11.3 94 2 0.7 18 25 17 100
NO 208/230-3-60 18725328.2 239 2 1.5 44/44 60/60 41/41 250/250
NO 460-3-60 414 506 14.7 130 2 0.8 23 30 21 136
14
NO 575-3-60 518 633 14.7 100 2 0.7 22 30 20 106
NO 208/230-3-60 18725348.1 245 2 1.5 68/6880/80 64/64 256/256
NO 460-3-60 414 506 18.6 125 2 0.8 28 45 26 131
FLA — Full Load Amps
LRA — Locked Rotor Amps
MOCP — Maximum Over Current Protection
NEC — National Electrical Code
RLA — Rated Load Amps
