Bryant Legacy Series Installation, Start-Up And Service Instructions

19
Table 16 — 569J*12-14D/E/F Electrical Data without Powered Convenience Outlet
Table 17 — 569J*12-14D/E/F Electrical Data with Powered Convenience Outlet
LEGEND
* Units are suitable for use on electrical systems where voltage sup-
plied to the unit terminals is not below or above the listed limits.
NOTES FOR TABLES 14-17
1. The MCA and Fuse values are calculated in accordance with the
NEC Article 440.
2. Motor RLA and LRA values are established in accordance with
Underwriters Laboratories (UL) Standard 1995.
3. The 575-v units are UL, Canada-listed only.
4. Unbalanced 3-Phase Supply Voltage. Never operate a motor
where a phase imbalance in supply voltage is greater than 2%.
Use the following formula to determine the percentage of voltage
imbalance.
Example: Supply voltage is 230-3-60
Determine maximum deviation from average voltage.
(AB) 227-224 = 3 v
(BC) 231-227 = 4 v
(AC) 227-226 = 1 v
Maximum deviation is 4 v.
Determine percent of voltage imbalance.
This amount of phase imbalance is satisfactory as it is below the maxi-
mum allowable 2%.
UNIT
SIZE
NOMINAL
POWER
SUPPLY
VOLTAGE
RANGE*
COMPRESSOR
No. 1
COMPRESSOR
No. 2
OFM POWER SUPPLY
DISCONNECT
SIZE
Volts Min Max RLA LRA RLA LRA Qty
FLA
(ea)
MCA
Fuse or
HACR
Brkr
FLA LRA
12
575 518 633 5.7 39 5.7 39 2 0.7 15 20 15 82
208/230-3-60 187 253 15.9 110 15.9 110 2 1.5 39/39 50/50 40/40 226/226
460-3-60 414 506 7.7 52 7.7 52 2 0.8 19 25 20 108
14
575-3-60 518 633 7.7 54 7.7 54 2 0.7 19 25 19 112
208/230-3-60 187 253 22.4 149 22.4 149 2 1.5 54/54 60/60 55/55 304/304
460-3-60 414 506 10.6 75 10.6 75 2 0.8 26 30 26 154
UNIT
SIZE
NOMINAL
POWER
SUPPLY
VOLTAGE
RANGE*
COMPRESSOR
No. 1
COMPRESSOR
No. 2
OFM POWER SUPPLY
DISCONNECT
SIZE
Volts Min Max RLA LRA RLA LRA Qty
FLA
(ea)
MCA
Fuse or
HACR
Brkr
FLA LRA
12
575-3-60 518 633 5.7 39 5.7 39 2 0.7 16 20 17 84
208/230-3-60 187 253 15.9 110 15.9 110 2 1.5 44/44 50/50 46/46 231/231
460-3-60 414 506 7.7 52 7.7 52 2 0.8 22 25 22 110
14
575-3-60 518 633 7.7 54 7.7 54 2 0.7 21 25 21 114
208/230-3-60 187 253 22.4 149 22.4 149 2 1.5 59/59 80/80 60/60 309/309
460-3-60 414 506 10.6 75 10.6 75 2 0.8 28 35 29 156
FLA — Full Load Amps
LRA — Locked Rotor Amps
MOCP — Maximum Over Current Protection
NEC — National Electrical Code
RLA — Rated Load Amps
% Voltage
Imbalance
= 100 x
max voltage deviation from average voltage
average voltage
AB = 224 v
BC = 231 v
AC = 226 v
Average Voltage =
(224 + 231 + 226)
=
681
= 227
33
% Voltage Imbalance = 100x
4
=1.78%
227
A
B
C
MOTOR
IMPORTANT: If the supply voltage phase imbalance is more than 2%,
contact your local electric utility company immediately.
