—15—
DETAILED COOLING CAPACITIES*
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
KW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
598B024-A Outdoor Section With FV4ANF003 Indoor Section - High Speed
600
72 29.76 14.87 1.78 27.81 14.05 1.91 25.82 13.24 2.04 23.82 12.45 2.16 21.77 11.66 2.28 19.62 10.86 2.39
67 26.74 17.46 1.74 24.91 16.63 1.86 23.07 15.82 1.98 21.24 15.03 2.10 19.34 14.23 2.21 17.40 13.43 2.31
63†† 24.54 16.81 1.71 22.83 15.98 1.82 21.11 15.18 1.94 19.35 14.36 2.05 17.58 13.57 2.14 15.79 12.79 2.24
62 23.95 20.00 1.70 22.24 19.17 1.81 20.53 18.34 1.92 18.82 17.50 2.03 17.10 16.62 2.13 15.50 15.50 2.22
57 21.78 21.78 1.66 20.56 20.56 1.78 19.33 19.33 1.89 18.08 18.08 2.01 16.81 16.81 2.12 15.50 15.50 2.22
700
72 30.82 15.67 1.83 28.72 14.82 1.96 26.61 13.99 2.09 24.49 13.18 2.22 22.30 12.36 2.34 20.03 11.53 2.45
67 27.70 18.67 1.79 25.75 17.82 1.91 23.81 16.98 2.03 21.84 16.16 2.15 19.83 15.33 2.26 17.78 14.51 2.36
63†† 25.44 17.96 1.76 23.63 17.11 1.87 21.78 16.27 1.99 19.90 15.43 2.10 18.03 14.61 2.20 16.14 13.80 2.29
62 24.81 21.62 1.75 22.99 20.73 1.86 21.20 19.84 1.98 19.38 18.88 2.09 17.69 17.69 2.19 16.27 16.27 2.30
57 23.08 23.08 1.72 21.77 21.77 1.84 20.43 20.43 1.96 19.07 19.07 2.08 17.69 17.69 2.19 16.28 16.28 2.30
800
72 31.61 16.39 1.87 29.41 15.52 2.01 27.21 14.68 2.14 24.96 13.84 2.27 22.68 13.00 2.38 20.33 12.15 2.50
67 28.43 19.79 1.83 26.40 18.92 1.96 24.35 18.06 2.08 22.28 17.21 2.20 20.18 16.37 2.31 18.05 15.51 2.41
63†† 26.14 19.02 1.80 24.22 18.15 1.92 22.27 17.28 2.04 20.32 16.42 2.15 18.37 15.58 2.25 16.38 14.70 2.34
62 25.47 23.09 1.79 23.60 22.15 1.91 21.71 21.13 2.02 19.90 19.90 2.14 18.41 18.41 2.25 16.89 16.89 2.36
57 24.18 24.18 1.77 22.76 22.76 1.89 21.35 21.35 2.02 19.90 19.90 2.14 18.42 18.42 2.25 16.90 16.90 2.36
900
72 32.25 17.07 1.91 30.00 16.20 2.05 27.67 15.33 2.18 25.33 14.47 2.31 22.98 13.62 2.43 20.55 12.76 2.55
67 29.04 20.87 1.88 26.93 19.98 2.00 24.77 19.10 2.13 22.62 18.23 2.25 20.46 17.36 2.36 18.24 16.44 2.46
63†† 26.72 20.05 1.84 24.69 19.14 1.96 22.67 18.26 2.08 20.66 17.39 2.19 18.60 16.48 2.30 16.57 15.54 2.39
62 26.04 24.47 1.84 24.09 23.42 1.95 22.19 22.19 2.07 20.63 20.63 2.20 19.06 19.06 2.31 17.43 17.43 2.43
57 25.15 25.15 1.82 23.68 23.68 1.95 22.16 22.16 2.07 20.64 20.64 2.20 19.06 19.06 2.31 17.44 17.44 2.43
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
High Speed
Indoor
Section Size
High Speed
Capacity Power Capacity Power
CC5A/CD5AA 024 0.98 1.12 CE3AA 024 0.98 1.03
030 1.00 1.12 030 0.99 1.03
036 1.00 1.13 036 1.00 1.03
CC5A/CD5AW 024 0.98 1.12 CK3BA 024 0.98 1.02
030 1.00 1.12 030 0.99 1.02
036 1.00 1.13 036 1.00 1.01
CE3AA 024 0.99 1.12 CK5A/CK5BA 024 1.00 1.02
030 1.00 1.13 030 1.00 1.02
036 1.00 1.14 036 1.00 1.01
CF5AA 024 0.99 1.12 CK5A/CK5BT 036 1.00 1.01
036 1.00 1.13 CK5A/CK5BW 024 1.00 1.02
CK3BA 024 1.00 1.12 030 1.00 1.02
030 1.00 1.13 CK5PA 024 1.00 1.02
036 1.00 1.13 030 1.00 1.02
CK5A/CK5BA 024 1.00 1.12 036 1.00 1.01
030 1.00 1.13 CK5PT 036 1.00 1.01
036 1.00 1.14 CK5PW 024 1.00 1.02
CK5A/CK5BT 036 1.00 1.14 030 1.00 1.02
CK5A/CK5BW 024 1.00 1.12
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE
030 1.00 1.13 CC5A/CD5AA 024 0.97 1.02
036 1.00 1.14 030 0.98 1.02
CK5PA
024 1.00 1.12 036 1.00 1.01
030 1.00 1.13 CC5A/CD5AW 024 0.97 1.01
036 1.00 1.14 030 0.98 1.02
CK5PT
036 1.00 1.14 036 1.00 1.01
CK5PW
024 1.00 1.12 CE3AA 024 0.98 1.02
030 1.00 1.13 030 0.99 1.02
036 1.00 1.14 036 1.00 1.02
FK4CNF
001 1.00 1.01 CK3BA 024 0.98 1.01
002 1.00 1.01 030 0.99 1.01
003 1.00 1.00 036 1.00 1.01
FV4ANF
002 1.00 1.01 CK5A/CK5BA 024 1.00 1.02
003 1.00 1.00 030 1.00 1.01
COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE
036 1.00 1.01
CC5A/CD5AA
024 0.96 1.02 CK5A/CK5BT 036 1.00 1.01
030 0.98 1.02 CK5A/CK5BW 024 1.00 1.01
036 1.00 1.02 030 1.00 1.01
CC5A/CD5AW
024 0.97 1.02 036 1.00 1.00
030 0.98 1.02 —— —
See notes on page 38.
