DETAILED COOLING CAPACITIES* continued
See notes on page 38.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
KW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
598B060-A, B Outdoor Section With FV4ANB006 Indoor Section - Low Speed
1050
72 39.76 21.24 1.94 36.67 20.07 2.10 33.65 18.94 2.25 30.65 17.85 2.39 27.67 16.78 2.54 24.69 15.73 2.67
67 35.45 25.93 1.92 32.63 24.76 2.07 29.85 23.64 2.21 27.10 22.54 2.35 24.38 21.45 2.48 21.68 20.35 2.61
63†† 32.40 24.81 1.91 29.77 23.65 2.05 27.16 22.51 2.18 24.60 21.41 2.31 22.09 20.32 2.43 19.61 19.16 2.55
62 31.56 30.45 1.91 29.05 29.05 2.04 27.06 27.06 2.18 25.10 25.10 2.32 23.15 23.15 2.46 21.12 21.12 2.59
57 30.98 30.98 1.90 29.02 29.02 2.04 27.07 27.07 2.18 25.11 25.11 2.32 23.15 23.15 2.46 21.12 21.12 2.59
1350
72 41.34 23.37 2.04 38.00 22.15 2.21 34.69 20.96 2.36 31.46 19.81 2.51 28.27 18.69 2.65 25.12 17.61 2.79
67 36.86 29.31 2.03 33.78 28.08 2.18 30.73 26.86 2.33 27.79 25.63 2.46 24.94 24.33 2.60 22.40 22.40 2.73
63†† 33.67 27.97 2.02 30.76 26.72 2.16 27.94 25.47 2.30 25.23 24.21 2.42 22.66 22.66 2.56 20.48 20.48 2.69
62 33.52 33.52 2.02 31.28 31.28 2.17 29.08 29.08 2.31 26.87 26.87 2.45 24.66 24.66 2.59 22.41 22.41 2.73
57 33.53 33.53 2.02 31.29 31.29 2.17 29.09 29.09 2.31 26.88 26.88 2.45 24.66 24.66 2.59 22.41 22.41 2.74
1650
72 42.29 25.25 2.15 38.72 23.97 2.31 35.25 22.74 2.47 31.87 21.55 2.62 28.54 20.40 2.77 25.27 19.28 2.90
67 37.66 32.34 2.14 34.38 30.98 2.29 31.22 29.58 2.44 28.19 28.19 2.57 25.69 25.69 2.72 23.23 23.23 2.86
63†† 34.36 30.74 2.12 31.32 29.34 2.27 28.41 27.85 2.41 25.82 25.82 2.54 23.50 23.50 2.68 21.16 21.16 2.81
62 35.35 35.35 2.13 32.94 32.94 2.28 30.50 30.50 2.43 28.09 28.09 2.57 25.70 25.70 2.72 23.23 23.23 2.86
57 35.36 35.36 2.13 32.95 32.95 2.28 30.51 30.51 2.43 28.10 28.10 2.57 25.70 25.70 2.72 23.24 23.24 2.86
1950
72 42.84 26.94 2.25 39.14 25.63 2.42 35.54 24.36 2.58 32.05 23.15 2.73 28.63 21.98 2.87 25.24 20.80 3.01
67 38.12 34.99 2.24 34.77 33.42 2.40 31.61 31.61 2.55 28.99 28.99 2.69 26.40 26.40 2.84 23.80 23.80 2.98
63†† 34.80 33.11 2.23 31.66 31.65 2.38 29.03 29.03 2.52 26.55 26.55 2.66 24.09 24.09 2.80 21.61 21.61 2.94
62 36.78 36.78 2.24 34.15 34.15 2.39 31.56 31.56 2.55 29.00 29.00 2.69 26.41 26.41 2.84 23.81 23.81 2.98
57 36.79 36.79 2.24 34.16 34.16 2.39 31.57 31.57 2.55 29.01 29.01 2.69 26.42 26.42 2.84 23.81 23.81 2.98
2250
72 43.19 28.56 2.35 39.39 27.23 2.52 35.69 25.94 2.68 32.11 24.70 2.83 28.60 23.49 2.98 25.12 22.18 3.12
67 38.48 37.30 2.34 35.16 35.16 2.50 32.40 32.40 2.66 29.66 29.66 2.81 26.94 26.94 2.96 24.21 24.21 3.10
63†† 35.14 35.14 2.33 32.36 32.36 2.49 29.70 29.70 2.63 27.10 27.10 2.77 24.52 24.52 2.92 21.88 21.88 3.05
62 37.91 37.91 2.34 35.14 35.14 2.50 32.41 32.41 2.66 29.68 29.68 2.81 26.96 26.96 2.96 24.22 24.22 3.10
57 37.93 37.93 2.34 35.15 35.15 2.50 32.43 32.43 2.66 29.68 29.68 2.81 26.96 26.96 2.96 24.23 24.23 3.10
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Low Speed
Indoor
Section Size
Low Speed
Capacity Power Capacity Power
CC5A/CD5AA 060 0.95 1.14 CE3AA 060 0.97 0.99
CC5A/CD5AW 060 0.96 1.14 CK3BA 060 0.98 0.99
CE3AA 060 0.97 1.14 CK5A/CK5BA 060 0.98 0.99
CK3BA 060 0.97 1.14 CK5A/CK5BT 060 0.98 0.99
CK5A/CK5BA 060 0.97 1.14 CK5A/CK5BX 060 0.99 0.99
CK5A/CK5BT 060 0.97 1.14 CK5PA 060 0.98 0.99
CK5A/CK5BX 060 0.98 1.14 CK5PT 060 0.98 0.99
CK5PA 060 0.97 1.14 CK5PX 060 0.99 0.99
CK5PT 060 0.97 1.14
COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE
CK5PX 060 0.98 1.14 CC5A/CD5AA 060 0.96 1.01
FK4CNB 006 1.00 1.00 CC5A/CD5AW 060 0.98 1.01
FV4ANB 006 1.00 1.00 CE3AA 060 0.99 1.02
COILS + 315(A,J)AV066110 VARIABLE SPEED FURNACE CK3BA 060 0.99 1.01
CE3AA 060 0.97 1.00 CK5A/CK5BA 060 0.99 1.01
CK3BA 060 0.98 1.00 CK5A/CK5BT 060 0.99 1.01
CK5A/CK5BA 060 0.98 1.00 CK5A/CK5BX 060 0.99 1.02
CK5A/CK5BT 060 0.98 1.00 CK5PA 060 0.99 1.01
CK5A/CK5BX 060 0.99 1.00 CK5PT 060 0.99 1.01
CK5PA 060 0.98 1.00 CK5PX 060 0.99 1.02
CK5PT 060 0.98 1.00
COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
CK5PX 060 0.99 1.00 CC5A/CD5AA 060 0.98 1.02
COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE CC5A/CD5AW 060 0.98 1.01
CC5A/CD5AA 060 0.97 1.00 CE3AA 060 0.99 1.02
CC5A/CD5AW 060 0.97 1.00 CK3BA 060 0.98 1.02
CE3AA 060 0.97 0.99 CK5A/CK5BA 060 0.99 1.01
CK3BA 060 0.98 1.00 CK5A/CK5BT 060 0.99 1.01
CK5A/CK5BA 060 0.98 0.99 CK5A/CK5BX 060 0.99 1.02
CK5A/CK5BT 060 0.98 0.99 CK5PA 060 0.99 1.01
CK5A/CK5BX 060 0.99 0.99 CK5PT 060 0.99 1.01
CK5PA 060 0.98 0.99 CK5PX 060 0.99 1.02
CK5PT 060 0.98 0.99
COILS + 355MAV060080 VARIABLE SPEED FURNACE
CK5PX 060 0.99 0.99 CC5A/CD5AA 060 0.99 1.08
COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE CC5A/CD5AW 060 1.00 1.08
CC5A/CD5AA 060 0.97 0.99 CE3AA 060 1.00 1.08
CC5A/CD5AW 060 0.97 0.99 CK3BA 060 1.00 1.08
