Manual EVoBASIC v.7 57 / 80
3.3.2- Advanced Functions
3.3.2.1- Stop-start control
This mode enables you to keep the equipment on permanently, so that
when the filtering pump starts up, it will instruct the chlorinator to start-
up. When the pump stops, the screen of the chlorinator will display the
message "stop".
To activate this mode, remove jumper "LK2" from the power board,
supply the chlorinator directly at 230 V, and connect the "filter" inlets in
parallel to the supply of the filtering pump. In this way, when the
filtration pump turns on, the “filter” input must be connected to 220V,
and when the pump stops, “filter” input connector must be at 0V.
