Bticino 353000 - Front View Components

6
2 Description
2.2 Front view
1 - Digital keypad + key illumination LED.
key for the selection of the door lock release code.
key for the replacement of the codes.
2 - Mini-USB programming connector.
3 - Programming pushbutton.
4 - Red LED on steady: access denied, or programming error.
5 - Green LED on steady: access granted, or programming successful.
