BÜCHI Labortechnik AG Product description | 3
Operation Manual Recirculating Chiller F-305 / F-308 / F-314 15/42
OUT
5
4
6
2
3
8
9
1
7
Fig.8: Recirculating Chiller F-314, rear view
1 Filler cap for coolant 6 Drain tap for coolant
2 Coolant inlet "IN" 7 Fuses
3 Coolant outlet "OUT" 8 Standard BUCHI communication port
(COM)
4 Tank overflow 9 Power supply connection
5 Air outlet
