Buderus AM10 - Wiring Diagrams and Sensor Data

AM10 - We reserve the right to make any changes due to technical modifications! 5
Installation manual 1
EMS-Bus
Thermostat
Outdoor sensor
Fig. 3 EMS-Bus
Fig. 4 Thermostat
On/Off
mode
°F
L
L ≤ 100 ft.
R ≤ 100 Ω
Ø = 18 AWG
Ø
Fig. 5 Outdoor sensor
mode
°F
L
L ≤ 100 ft.
R ≤ 100 Ω
Ø = 18 AWG
Ø
