Parts List 13
55
We reserve the right to make any changes due to technical modifications!
Installation, Operation and Maintenance Manual Sealed Combustion Gas Boiler Logano GA244 • Issue 02/2004
Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de
Control panel GAW028 (Fig. 43)
Item.
No.
Part description
Buderus
Part number
Model 37
Quantity
Model 44
Quantity
Model 53
Quantity
Model 62
Quantity
10 Control panel GAW 028 00 compl. "US" - 63026298 63026298 63026299 63026300
20 Relay 24V AC 1xS 120V AC/15A 63015750 1 1 1 1
30 Sheet metal screw DIN7981 F ST3,5x6,5 A3 see mounting-material for GAW027/GAW028 „US“
40 Terminal strip 4 qmm 4-pin see mounting-material for GAW027/GAW028 „US“
50 Sheet meatl screw DIN7981 F ST3,5x16 A3K see mounting-material for GAW027/GAW028 „US“
60 Middle panel GA244 "US" see boiler jacket 1 1 1 1
70 Ignition module S 8600H1006 63015743 1 1 1 1
80 Screw ST3,9x9,5 A3K see mounting-material for GAW027/GAW028 „US“
90 Cover plate for ignition module GAW028 "US" 63026301 1 1 1 1
100 Tooth lock washer DIN6797 A4,3 A3K see mounting-material for GAW027/GAW028 „US“
110 Hose AWG 2x18 063/076 63015745 1 1 1 1
120 Cabling tree GAW 022/024/026/027 63015746 1 1 1 1
130 Temperature sensor 32004955-003B 63015749 1 1 1 1
140 Blank piece für 1/4 ciruit sensor 07060110 2 2 2 2
150 Distance spring 05446800 1 1 1 1
160 Sensor bracket 07060986 1 1 1 1
170 Transformer 120V/24V "US" compl. 63015748 1 1 1 1
180 Aquastat Relay L7148F 63015742 1 1 1 1
190 Sheet metal screw DIN7981 C ST3,5x25 A3K see mounting-material for GAW027/GAW028 „US“
200 Interconnecting cable 63015744 1 1 1 1
210 Sheet metal screw DIN7981 C ST2,9x16 A3K see mounting-material for GAW027/GAW028 „US“
220 3-pin plug black 93.923.4354 05493464 1 1 1 1
230 3-pin female connector black 93.031.3253.0 07060911 1 1 1 1
240 3-pin plug green/black 05493465 1 1 1 1
250 3-pin female connector green 07060912 1 1 1 1
260 Sheet metal screw DIN7981 C ST2,9x25 A3K see mounting-material for GAW027/GAW028 „US“
270 5-pin female connector black 07060913 1 1 1 1
280 Sheet metal screw DIN7981 F ST3,5x9,5A3K see mounting-material for GAW027/GAW028 „US“
