Installation, Operation and Maintenance Manual Sealed Combustion Gas Boiler Logano GA244 • Issue 02/2004
Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de
Parts List13
Mounting-material for GAW027/GAW028 „US“ 63015810
The mounting material contains the following components:
30 Sheet metal screw DIN7981 F ST3,5x6,5 A3 10 10 10 10
40 Terminal strip 4 qmm 4-pin 1 1 1 1
50 Sheet metal screw DIN7981 F ST3,5x16 A3K 5 5 5 5
80 Screwe ST3,9x9,5 A3E 5 5 5 5
100 Tooth lock washer DIN6797 A4,3 A3K 5 5 5 5
190 Sheet metal screw DIN7981 C ST3,5x25 A3K 5 5 5 5
210 Sheet metal screw DIN7981 C ST2,9x16 A3K 5 5 5 5
260 Sheet metal screw DIN7981 C ST2,9x25 A3K 4 4 4 4
280 Sheet metal screw DIN7981 F ST3,5x9,5A3K 2 2 2 2
Tab. 17 Control panel GAW028
Control panel GAW028 (Fig. 43)
Item.
No.
Part description
Buderus
Part number
Model 37
Quantity
Model 44
Quantity
Model 53
Quantity
Model 62
Quantity
