2
MA671635_13.1 [Original Instructions] 1/23/2012
Unpacking
The VibroMet 2 has been carefully packaged to protect it during transit from the factory to your location.
Carefully unpack and check contents. If any components are missing or damaged, save the packing list
and materials and advise the carrier and Buehler of the discrepancy.
Carefully unpack and check that the following items have been received:
• AK Kit #120
40-7222 MicroCloth
®
12-inch, PSA backed, Polishing Cloth
40-7742 MasterTex
®
12-inch, PSA backed, Polishing Cloth
• Load fixture
• MasterMet
®
Colloidal Silica Suspension 0.06 μm (2 oz)
• MicroPolish
®
II Deagglomerated Alumina Suspension (6 oz)
Equipment Damage. The VibroMet 2 weighs 175 lbs (80 kg) Follow local safety practices to safely
lift the VibroMet 2 from the shipping carton. Improper lifting can result in personal injury or
machine damage.
The VibroMet 2 is bolted to a wood base for protection during shipping. Open areas are provided at the
corners of the base for ease of lifting. Use the removable handles at the bottom of the machine to lift the
VibroMet 2 out of the carton.
Do not lift the VibroMet 2 by the clamp or bowl assembly. Position the VibroMet 2 on a table so it
overhangs on the edge and remove the bolts securing the VibroMet 2 to the wood base.
