Buffalo GL190 - Page 6

NO. DESCRIPTION NO. DESCRIPTION NO. DESCRIPTION
1 WireWhip 22 Nut 60 Wormwheel
2 SpiralDoughHook 24 GearBox 69
Motor(WithTool)
3 FlatBeater 24 GearBox 61 Oilseal
4 SafetyGuard 25 EndCap 62
GreenButton
5 BowlAssembly 26 InternalGear 63
RedButton
6 Cap 27 Gear 64 Panel
7 Spring 28 OperatingShaft 65 MotorHousing
8 PinShaft 29 Bearing 66 Key
9 ShiftingYoke 30 OilSeal 67 ShaftWormGear
10 CamGear 31 WorkingShaft 68 WormWheel/Gear
11 TransmissionPlate 32 RetainerPin 70 RearCasing
12 TransmissionPlate 33 Spring 70 RearCasing
13 DriveShaft 34 PressingPlate 71 RearPanel
14 GearMech 35 TransmissionSupport 72 Handle-shifter
15 Hood 36 Bearing 73 CrankLever
16 Nut 38 CirclipsforShaft 74 ConnectingRod
17 PressingPlate 46 Bushing 75 Pillar
18 PlugCover 47 OilSeal 76 ClampPlate
19 Cog 48 LockingClamp 77 ClampPlate
23 MainShaft 49 BowlSupport 78 Spring
37 Spacer-Lower 50 Case 79 MicroSwitch/DistanceSwitch
39 RingGasket 51 Nut 80 OverloadSwitch
40 Gear 52 Bearing 81 PowerCord
41 Bushing 53 Gear 82 Gland
42 Sleeve 54 Key 83 ContactSwitch
43 ClawGear 55 CirclipsforShaft 84 Capacitor
44 Washer 56 Gear 85 StartCapacitor
45 Bearing 57 Bushing 86 RubberPadandScrew
20 DeclutchShiftShaft 58 Gear
21 Washer 59 Washer
GL191
