Buffalo GL190 - Page 8

Exploded diagram and spare parts list GJ461
No.
Description
No.
Description
No.
Description
1
Dough Hook
33
Top Hat Valve
Cap
67
Gear Shaft
2
Flat Beater
34
Flat Valve Cap
68
Gear
3
Wire Whip
35
Bearing
69
Bushing
4
Safety Guard
36
Spacer
70
Gear
5
Bowl
37
38
Gear
71
Gear
6
Upper Panel
39
Gear
72
Pressing Plate
7
Screw
40
Bushing
73
Spacer
8
Spring
41
Shaft Sleeve
74
Nut
9
Pin Shaft
42
Gear
75
Pressing Plate
10
Shifting Yoke
43
Clamping Plate
76
Bearing
11
Cam Gear
44
Bearing
77
Worm Gear
and Shaft
12
Transmission
Plate
45
Bushing
78
Key
13
Drive Shaft
46
Seal
79
Circlips
14
Gear Mech
47
Pillar
80
Circlips
15
Knob
48
Locking Clamp
81
Spacer
16
Extension Bar
49
Support
82
Motor
17
Attachment
Hub
50
Clamping Plate
83
Rubber
Stopper
18
Overload
Switch
51
Nut
84
Green Button
19
Power Cable
52
Base
85
Red Button
20
Gland
53
Bearing
86
Crank
21
Contact
Switch
54
Transmission
Shaft Support
87
Crank lever
22
Hood Ring
55
Key
88
Connecting
Rod
23
Circlips
56
Circlips
89
Spring
24
Planet Gear
57
Gear
90
Plate
25
Operating
Shelf
58
Bushing
91
Clamping Plate
26
Bearing
59
Gear Box
92
Distance
Switch
27
Seal
60
Worm Wheel
93
Capacitor 1
28
Pin
61
Panel
94
Capacitor 2
29
Working Shaft
62
Casing
95
Switch
Mounting
30
Shaft
63
Rear Panel
96
Spring
31
Pressing Plate
64
Internal Gear
97
Washer
32
Main Shaft
65
Switch Axle
98
Fin (left-hand
side)
33
Nut
66
Seal
99
Fin (right-hand
side)
