LAN Interface
Standards Compliance
IEEE 802.3bz (2.5GBASE-T), IEEE 802.3ab (1000BASE-T),
IEEE 802.3u (100BASE-TX), IEEE 802.3 (10BASE-T)
Data Transfer Rates 2.5 Gbps, 10/100/1000 Mbps (auto sensing)
Number of Ports 1
Connector Type RJ-45 8-pin (auto MDI-X)
Supported Protocols TCP/IP
Network File Services SMB/CIFS, FTP/FTPS, NFS, HTTP/HTTPS, SNMP
MTU Sizes 1,500–9,219 bytes
USB Interface
Standards Compliance USB 3.2 Gen 1/2.0
Data Transfer Rates
USB 3.2 Gen 1: max. 5 Gbps
USB 2.0: max. 480 Mbps
Number of Ports 2 × USB 3.2 Gen 1, 1 × USB 2.0
Connector Type Type A
Internal Drive
Number of Drive Bays
LS710D: 1
LS720D: 2
Drive Interface SATA 6 Gbps
Supported RAID LS720D: 0, 1, JBOD (individual drives)
Replacement Drive
LS720D: Buffalo OP-HDBST series drive
Note: The replacement drive should be the same
capacity as the original drive. The drives listed above are
available from the Buffalo website.
Others
Power Supply AC 100–240 V, 50/60 Hz
Power Consumption
LS710D (4 TB or smaller model): max. 24 W
LS710D (8 TB model), LS720D (8 TB or smaller model):
max. 36 W
LS720D (16 TB): max. 48 W
Dimensions (W × H × D,
excluding protruding parts)
LS710D: 60 × 128 × 207 mm; 2.4 × 5.0 × 8.1 in.
LS720D: 92 × 128 × 207 mm; 3.6 × 5.0 × 8.1 in.
Weight
LS710D: approx. 1.3 kg; 2.9 lbs
LS720D: approx. 2.4 kg; 5.3 lbs
Operating Environment
Temperature: 5–40°C; 41–104°F
Humidity: 20–80% non-condensing
Compatible Devices
Windows PCs, Intel Mac computers, iOS devices,
and Android devices with wired or wireless Ethernet
connection.
Supported OS
Windows 10, 8.1
Windows Server 2019, 2016, 2012 R2, 2012
Windows Server IoT 2019 for Storage, Windows Storage
Server 2016, 2012 R2, 2012
macOS 10.15, 10.14, 10.13
iOS 10 or later
Android 7.0 or later
203
