12
1. Main control
2. Jet pump 1
3. Jet pump 2
4. Control center box
5. Ozone generator box
6. Water heater
7. Safety certicate and serial number
8. Serial number sticker (visible with door installed)
9. Drain outlet
10. Ozone feed line
11. LED light
12. Support stud
13. Door attachment notch in support stud
14. ABS spa base pan
15. Acrylic spa shell
1
2
3
4
5
6
10
7
8
9
11
12
12
1212
13
13
13
13
14
15
Spa Equipment Compartment A Series, R Series, X Series, STIL
[A7 Pictured]
