BullFrog A7 - Equipment Compartment

11
1. Jet pump 1
2. Jet pump 2
3. Jet pump 3
4. Control center box
5. EOS ozone generator box
6. EOS mixing module
7. Safety certicate and serial number
8. Serial number sticker (visible with door installed)
9. Drain outlet
10. Filter weir and intake assembly
11. Water heater
12. Support stud
13. Cabinet attachment notch in support stud
14. ABS spa base pan
15. Audio control box
16. Acrylic spa shell
17. Pump access hinge assembly
1
2
3
4
5
6
10
7
8
9
11
12
12
12
12
14
13
13
14
15
16
Spa Equipment Compartment M Series
[M8 Pictured, shown with corner panels removed]
Front Compartment
Corner Compartment (left front)
16
10
12
12
13
12
17
17
EQUIPMENT COMPARTMENT
