Page 5
Site Requirements
1. Counter able to support at least 150 pounds (68kg).
2. Counter area large enough for machine and refrigerator.
3. Minimum clearance of 2˝ around machine.
Electrical-SureTamp
1. 208VAC, 2 wires with ground.
2. Dedicated 30A circuit with proper breaker and receptacle.
3. Receptacle within 5 feet (1.5 meter) of machine.
4. Power cord with or without plug supplied with machine.
Electrical-refrigerator
1. 120VAC, 2 wires with ground.
2. Dedicated 15A circuit with proper breaker and receptacle.
3. Receptacle within 5 feet (1.5 meter) of machine.
4. Power cord with plug supplied with machine.
5. Requires minimum 2 inches (50mm) in back and top.
SITE REQUIREMENTS
49985 090914
WARNING -
The brewer must be disconnected from the power source until specifi ed in Initial Set-Up.
Refer to Data Plate on the Brewer, and local/national electrical codes to determine circuit requirements.
ELECTRICAL REQUIREMENTS
CAUTION – Improper electrical installation will damage electronic components.
1. An electrician must provide electrical service.
2. Determine the available on-site electrical service.
3. Using a voltmeter, check the voltage and color coding of each conductor at the electrical source.
4. If wiring the machine for operation on 208 volts with a power supply cord, the power supply cord must
be UL Listed Flexible Cord Type SOO or SOOW, 600V, No. 10 AWG, 3 Conductor, Rated 90°C minimum.
Attachment Plug Cap must be UL Listed, NEMA 6-30P or L6-30P Confi guration. Rated 250V, 30 AMPS.
The Power supply Cord must be at least 3 feet long and maximum 6 feet long (measured from strain
relief to end of the attached Plug Cap).
RELEASED FOR PRODUCTION
DIR Num: 49985.0000 17, September 2014
