Bunn DUAL SH DBC - Page 13

Page 13
PROGRAMMING FUNCTIONS (cont.)
PROGRAM FLOW DIAGRAM (Cont.)
TRANSFER
COMPLETE
ENABLE ADS?
NO DONE YES
SET TEMP: 200°F
(-) DONE (+)
SET READY 195°F
(-) DONE (+)
0 REFILL 155
(-) DONE (+)
L SPRY OZ/M 39.2
(-) DONE (+)
R SPRY OZ/M 39.2
(-) DONE (+)
Continue to (F)
(G)
(E)
PRESS BREW TO
SET 1st ON-TIME
1st ON TIME: X:XX
(-) DONE (+)
OFF TIMES: X:XX
(-) DONE (+)
LAST ON: Prel
(-) DONE (+)
3 BATCHES DONE?
NO YES
Return
to (H)
(I)
PRESS BREW TO
END 1st ON-TIME
PRESS BREW TO
END OFF-TIME
PRESS BREW TO
END LAST ON-TIME
(K)
Return to (J)
Return
to (L)
29877.2 121504
