03 ATEX5014 X - 11
english
2.1.5 Use in petrol pumps
DANGER!
Risk of explosion if the device is opened!
• The valves may only be dismantled by the manufacturer. The always
represent a closed system!
The Type 0641, 2832, 6013 and 6022 solenoid valves (Inner Zone 0) are
used for explosive steam/air mixtures in the in gas feedback equipment of
filling stations.
Bolted together as a block
Type 0641 and Type 2832
The magnetic coil 64.- is mounted on the body using 4 sealed M4x59 cy-
linder screws.
The magnetic coil AC10-..-.-... is secured onto the fitting using a sealed nut.
