Burkert 0641 - Assembly

03 ATEX5014 X - 19
english
WARNING!
Pressurised system!
Interventions in the pneumatic system represent an acute risk of injury.
• Work on the pneumatic system may only be carried out by qualified and
instructed personnel using appropriate tools.
• First switch off pressure before disconnecting lines and valves.
• Observe the flow direction during installation!
• Observe the applicable accident prevention and safety regulations for
pneumatic systems!
The type 0641, 2832, 6013 and 6022 units may only be installed in petrol
pumps between the pump valve and the gas feedback pump. This use must
be based on EN 60079-14.
Please observe the maximum permissible environmental temperature range.
4.1 Assembly
NOTES!
Installation in any position.
Preferably with solenoid system mounted at the top
Activity Notes
Clean the pipe runs
Installation in any position Preferred direction with drive mounted
at the top
Connect a dirt-trap (strai-
ner) upstream
Note the direction of flow!
Screwing on the pipe run Note the direction of flow!
Installation / Dismounting
Note for types 0641 and 2832
Always connect the earth
conductor!
Note for units with connecting cable
The connecting cable and the coil are
moduled together. They must not be
dismantled!
Make electrical connections
