3.2 Technical data for the type 6013 and 6022 units
Temperature class T3
Electromagnet
used
Type AC10, PTB 00 ATEX 2129X
Circuit function of
the valve
A = normally closed
Type of current Universal current (0 Hz ... 60 Hz)
Rated voltage 12 V ... 400 V (±10 %)
Rated current
Coil size 5 Coil size 6
0,68 ...0,02 A 0,8 ... 0,02 A
Power limit at
steady state
Coil size 5 Coil size 6
7 W 9 W
Maximal permis-
sible ambient tem-
perature range
Single mounting
Coil size 5 Coil size 6
PD47: -30 °C ... +60 °C
PD60: -40 °C ... +60 °C
PD53: -30 °C ... +60 °C
PD66: -40 °C ... +60 °C
Type of protection IP 65 according to EN 60529 (DIN VDE 0470 Part 1)
Electrical connec-
tion
Electrical connection variants according to approval
of the type AC 10 electro-magnets PTB 00 ATEX
2129X (see following description).
Type of protection
/ Marking of the
magnetic coil
The type of protection changes depending on the
electrical connection variants (the components used):
II 2G Ex m II T4, T5, T6 or
II 2G Ex em II T4, T5, T6 or
II 2D Ex tD A21 IP65 T -40/-30 °C ...
(see following description).
Type of protection
/ Marking of the
complete unit
The marking changes depending on the electrical
connection variants (the components used):
II 1 / 2 G Ex m II T3 or II 1 / 2 G Ex em II T3
(see following description).
NOTES!
Only individual mounting is permissible for units of the types 6013 and
6022.
