03 ATEX5014 X - 13
english
3 TECHNICAL DATA
DANGER!
Risk of explosion!
Exceeding the technical data indicated on the rating plate increases the
explosion risk!
Never exceed the technical data indicated on the rating plate!
PTB approval number of the magnetic coil
Fuse
... A
CE designation
PTB certification No.
Rating plate of the complete unit Rating plate of the magnetic coil
Orifice - Sealing material - Body material Mode of protection / temperature code
Port size for fluid part - Pressure range Coil type
Voltage (±10 %) - Power Voltage (±10 %) - power rating
variable code - PTB-Approval number Serial no. of the coil
Approval - Protection Class - Temperature
class
Ident. no / date of production
Serial no. of the coil /CE designation Space for barcode
Ident. no / date of production
Space for barcode
Valve type Code for the marking of units for use in the gas feedback sys-
tems of petrol pumps (Coil size)
0641 / 2832 PD 36
6013 / 6022 PD 97
