DASH FM & DASH X FM
ENG FRA ESP
Adjusting the Harness
The shoulder straps can be adjusted to two
positions according to the child’s size.
Access the Harness Connector via
the rear of the Bicycle Seat.
Pass the Harness Connector through
the upper harness adjustment hole
only (not the seat pad), then rotate
the Harness Connector so that it is
secure against the rear seat back.
Rotate the Harness Connector
sideways, and slide it through the
lower harness adjustment hole
and the slot in the seat pad.
Repeat steps 1–3 for the other shoulder
strap. Ensure that harness straps are not
twisted during harness adjustment.
1
3
2
4
note
I f you are adjusting from the upper harness
position to the lower harness position, the Harness
Connector will need to be passed back through the
slot in the seat pad before passing it through the
lower harness adjustment hole.
