XIII. Repair Parts (continued)
Key
No.
Description
(Quantity) Part Number
APX399 APX500 APX800
6A Jacket, Rear/Bottom Panel 103406-02 103407-01 N/A
6B Jacket, Left Side Panel 102776-06 102776-07 103232-01
6C Jacket, Right Side Panel 102776-02 102610-01 103233-01
6D Partition Shelf Assembly 102831-06 102831-07 103237-01
6E Jacket, Top Panel 101218-06 101218-07 103234-01
6F Heat Exchanger Support Assembly, Right Side 101232-06 101232-07 103228-01
6G Heat Exchanger Support, Left Side 101224-06 101224-07 103227-01
6H Bracket, High Voltage Terminal 102780-01
6J Bracket, Rear HX Support 101381-01
6K Jacket Support Bracket (2) 101593-01 (1) 101593-01 N/A
6L Lower Front Door Assembly 101227-02 101227-01
6M Jacket, Upper Front Panel 101509-01
6N Bracket, Right Clip 101508-01
6P Rubber Pad, Right Clip 101245-01
6R Draw Latch 101037-01
6S
Bracket, Left Clip 101507-02 N/A
Bracket, HX Strap N/A 103229-01
6T Access Panel (5’ x 16’) N/A 102612-01 N/A
6U Gasket, Access Panel (5’ x 16’) N/A 102613-01 N/A
6V Bracket, Gas Train N/A 102611-01 103240-01
6W Gasket, Access Panel (5’ x 8’) (1) 102877-01 (2) 102877-01 (6) 102877-01
6X Jacket, Rear Panel N/A 103230-01
6Y Access Panel (5’ x 8’) (1) 102873-01 (2) 102873-01 (6) 102873-01
6Z Control, Slid Tray 102777-01 103336-01
6AA Gasket, Rear to Base & Partition N/A 103241-01
6BB Gasket, Rear to Side N/A 103242-01
6CC Gasket, Side to Base & Partition N/A 103243-01
6DD Gasket, Side to Base Support N/A 103244-01
6EE Gasket, Side to Header Strap N/A 103245-01
6FF Gasket, Side to HX Support N/A 103246-01
6GG Heat Exchanger Support, Front/Rear N/A 103231-01
6HH Base Pan N/A 103226-01
6JJ Bracket, Partition Shelf Support N/A 103239-01
Nylon Glide (4) 8186006 (6) 8186006
