SECTION I - GENERAL INFORMATION
Boiler
Model
Number
of
Sections
Dim. A
(Inches)
* Burner Dimension B (Inches)
Minimum Flue
Bafe Installation
Clearance Dim. C
(Inches)
Vent (Flue Outlet
Damper)
Connection Size
Dim. D (Inches)
Approx. Weight of
Sections - LBS.
(Block Assy.)
Approx.
Shipping
Weight - LBS.
(KD Boiler)
Beckett Power Flame
CF CG C JR
MPC4 4 33-3/4 10-1/4 20-3/4 29-5/8 23 35 7” 1875 2370
MPC5 5 40-1/2 12-1/4 21-3/4 29-5/8 23 35 7” 2321 2821
MPC6 6 47-1/4 20-1/2 28-1/2 29-5/8 23 41 8” 2767 3272
MPC7 7 54 20-1/2 28-1/2 29-5/8 23 48 8” 3213 3733
MPC8 8 60-3/4 21 29 34-5/8 25-3/4 55 8” 3659 4194
MPC9 9 67-1/2 21 29 34-5/8 25-3/4 61 10” 4105 4655
MPC10 10 74-1/4 21 29 34-5/8 25-3/4 68 10” 4551 5116
MPC11 11 81 22-1/2 29 34-5/8 25-3/4 68 10” 4997 5577
MPC12 12 87-7/8 22-1/2 29-3/8 34-5/8 --- 82 10” 5443 6073
MPC13 13 94-5/8 22-1/2 29-3/8 34-5/8 --- 88 12” 5889 6544
MPC14 14 101-3/8 22-1/2 29-3/8 34-5/8 --- 88 12” 6335 7015
MPC15 15 108-1/8 22-1/2 29-3/8 39-1/2 --- 82 12” 6781 7486
MPC16 16 114-7/8 26-3/8 29-3/8 39-1/2 --- 75 12” 7227 7957
MPC17 17 121-5/8 26-3/8 29-3/8 39-1/2 --- 75 12” 7673 8438
MPC18 18 128-3/8 26-3/8 29-3/8 39-1/2 --- 68 12” 8119 8919
* Burner control panel conguration may change this dimension.
Table I: Dimensional Information
