Burnham V7 SERIES User Manual

33
Item
No.
Description Part No. V72 V713 V73 V714 V74 V75 V76 V77 V78 V79
BARE BOILER ASSEMBLY (See Page 32 for Illustration)
1
Front Section (Non-Htr.), Machined Water 71727019 1 --- 1 --- 1 1 1 1 1 1
Front Section (Non-Htr.), Machined Water 71727015 --- 1 --- 1 --- --- --- --- --- ---
1A Front Section (Non-Htr.), Machined Steam 71727018 --- --- 1 --- 1 1 1 1 1 1
2
Front Section w/Htr. Opening, Machined
Water
71727016 --- --- 1 --- 1 1 1 1 1 1
2A
Front Section w/Htr. Opening, Machined
Steam
71727017 --- --- 1 --- 1 1 1 1 1 1
3
Center Section 7172202 --- 1 --- 2 --- --- --- --- --- ---
Center Section 71727021 --- --- 1 --- 2 3 4 5 6 7
4 Narrow Back Section (Non-Htr.), Machined 7172204 --- 1 --- 1 --- --- --- --- --- ---
4A
Wide Back Section (Non-Htr.), Machined
Water
71727033 1 --- 1 --- 1 1 1 1 1 1
4B
Wide Back Section (Non-Htr.), Machined
Steam
71727034 --- --- 1 --- 1 1 1 1 1 1
5
Rear Section w/Htr. Opening, Machined 7172203 --- 1 --- 1 --- --- --- --- --- ---
Rear Section w/Htr. Opening, Machined 71727036 --- --- 1 --- 1 1 1 1 1 1
6 5" Cast Iron Slip Nipple 7066003 1 --- 2 --- 3 4 5 6 7 8
7 2½" Cast Iron Slip Nipple 7066001 1 4 2 6 3 4 5 6 7 8
8 Rear Target Wall Insulation 8202701 1 1 1 1 1 1 1 1 1 1
8A
Combustion Chamber Liner, ½" x 23" x 4" 82027023 1 --- --- --- --- --- --- --- --- ---
Combustion Chamber Liner, ½" x 24" x 5" 82022033 --- 1 --- --- --- --- --- --- --- ---
Combustion Chamber Liner, ½" x 23" x 8" 82027031 --- --- 1 --- --- --- --- --- --- ---
Combustion Chamber Liner, ½" x 24" x 9" 82022043 --- --- --- 1 --- --- --- --- --- ---
Combustion Chamber Liner, ½" x 23" x 12" 82027041 --- --- --- --- 1 --- --- --- --- ---
Combustion Chamber Liner, ½" x 23" x 16" 82027051 --- --- --- --- --- 1 --- --- --- ---
Combustion Chamber Liner, ½" x 23" x 20" 82027061 --- --- --- --- --- --- 1 --- --- ---
Combustion Chamber Liner, ½" x 23" x 24" 82027071 --- --- --- --- --- --- --- 1 --- ---
Combustion Chamber Liner, ½" x 23" x 28" 82027081 --- --- --- --- --- --- --- --- 1 ---
Combustion Chamber Liner, ½" x 23" x 32" 82027091 --- --- --- --- --- --- --- --- --- 1
9
Tie Rod, 3/8"-16 x 7¾" Lg. 80861072 2 --- --- --- --- --- --- --- --- ---
Tie Rod, 3/8"-16 x 12½" Lg. 80861010 --- 2 2 --- --- --- --- --- --- ---
Tie Rod, 3/8"-16 x 17" Lg. 80861011 --- --- --- 2 2 --- --- --- --- ---
Tie Rod, 3/8"-16 x 20¾" Lg. 80861012 --- --- --- --- --- 2 --- --- --- ---
Tie Rod, 3/8"-16 x 25¼" Lg. 80861013 --- ---- --- --- --- --- 2 --- --- ---
Tie Rod, 3/8"-16 x 27½" Lg. 80861014 --- --- --- --- --- --- --- 2 --- ---
Tie Rod, 3/8"-16 x 31½" Lg. 80861015 --- --- --- --- --- --- --- --- 2 ---
Tie Rod, 3/8"-16 x 36½" Lg. 80861036 --- --- --- --- --- --- --- --- --- 2
CONTINUED ON PAGES 34 AND 35
