For any help concerning set up and use of your TV please call the Customer Helpline: 0871 2000 463
IMPORTANT - Before drilling any holes in the wall ensure you are not drilling where there could be any electric wires, water or
gas pipes.
1) Remove the four screws highlighted below.
2) The wall mount can now be easily attached to the mounting holes on the rear of the TV. These holes are
indicated in the picture below.
For VESA wall mounting information please refer to the Technical Specifi cation page.
For optimum viewing, if wall mounting the TV higher
than eye level, the TV should be tilted downwards so
that the TV’s screen is ‘face on’.
See fi g 1 and 2 below.
IMPORTANT – If wall mounting this TV, only use the
screws already provided in the wall mounting holes.
Using other screws which are longer could cause
irreparable damage to internal parts.
TV
fi g 1
fi g 2
Viewing angle
Viewing angle
INCORRECT
CORRECT
TV
Wall Mounting
