6
3 Camera Overview
1 Microphone 8 Lens
15
SIM card slot
( for GPRSmodel)
2 PIR sensor 9 TFT screen
3 IR LED 10 SD card slot 16 Speaker
4 Lock Buckle 11 keypad 17 Tripod Nut
5 Light Sensor 12
Power/modes
switch
18 DC In
6 Lock Hole 13 DC Port 19 Battery Slot
7 Indicator Light 14
USB/TV Cable
Port
20 Battery slot cover
3.1 Microphone
To collect the scene of the environment sound when taking
video, you can also close this function in the software.
3.2 PIR sensor
This is the PIR sensor window, please don’t cover when using.
The material is relatively fragile, in order to avoid damage, please do
not press firmly.
