Butterfly Amicus 3000 Plus - Technical Data; Spare Parts List

 2005 Tamasu Butterfly Europa GmbH
Am Schürmannshütt 40a, 47441 Moers
Phone +49 2841 905320 • Fax +49 2841 9053220
Website: www.butterfly-world.com
Technical data / spare parts list
Mains current: 110 V, 50 Hz AC voltage, approx. 50 w
Shock-hazard protection class: I.
The machine can be put into operation in the outdoor temperature range from 0 - 40 °C.
Fuses: 2 T 400 mA
Spare parts list
42. 3000-
100
Control unit 43. 3000-
102
Ball speed motor
44.
3000
-
104
Charging motor
45.
3000
-
106
Pivot head motor
46.
3000
-
108
Ejection disc
47.
3000
-
110
Axle for ejection disc
48. 3000-
112
Ball placing mechanism 49. 3000-
114
Remote control
50. 3000-
116
Fuse (T 400 mA/250 V) 51. 3000-
118
Transformer
52.
3000
-
120
Casing for robot
foot
53.
3000
-
122
Shell tube
54.
3000
-
124
Motor casing ( 2 off)
55.
3000
-
126
Ball container
56. 30001
28-
Collecting net 57. 3000-
130
Net supporting frame
58.
3000
-
132
Extension cable for
remote control
59.
3000
-
134
60. 3000-
136
Holder for control unit
Motor for height adjustment
Further spare parts on request!
The electric product - ball machine AMICUS 3000 Plus - was subject to a type test and the type and
version of the designs presented were found to be in conformity with the standard stated.
EN 61010-1:1993+3000.2 (1995) = IEC 1010-1:1990 - 3000.1,2
EN 50081-1:1992 ENV 50140:1993
EN 55014:1993 EN 61000-4-2:1995
EN 61000-3-2:1995 EN 61000-4-4:1995
EN 61000-3-3:1995 EN 61000-4-5:1995
EN 55104:1995 EN 61000-4-11:1994
as can be seen from the test reports with the Nos. E-00136 and E-00136/1.
This test report states that the robot AMICUS 3000 Plus may bear the CE mark.
