2005 Tamasu Butterfly Europa GmbH
Am Schürmannshütt 40a, 47441 Moers
Phone +49 2841 905320 • Fax +49 2841 9053220
Website: www.butterfly-world.com
C O N T R O L P A N E L Q U I C K R E F E R E N C E G U I D E
Speed controls (range: 1 to 22) Controls the speed of the ball. Set to "22" for very fast, "1" for very slow
Spin controls (range: -4 to +6) Controls the spin of the ball. Set to -4 for heavy underspin, 0 for no-spin,
6 for heavy topspin.
Distance controls (range: 0 to 10) Controls the long-short distance (and height of balls). Set to 10 for
longer (higher) balls, 3-4 for shorter (lower) balls, and 0-2 for serves (delivers balls to robot side of table
first).
Ball number buttons (Located above "Ball A, B, C, and D" labels.) Sets the ball number for this ball type
to 1, 2, 3 or 4 balls. (For a total of 16 balls for A, B, C, and D)
Memory step & clear buttons The memory "step" button is used to select various memory positions.
The "save" button allows saving of a pattern into memory. These buttons are used together to clear
patterns from memory.
Left-Right position (5 to 5) controls for A, B, C, D. Horizontal levers used to set the left-right positions
for positions A, B, C, D.
Play & Pause controls Enables setting of the play/pause timer: intervals of continuous play for 10sec to
10min, with 5sec to 2min pauses between each play interval.
Step & Sample buttons The "step" button is used to select the next ball within a ball type or within a
pattern. The "sample" button is then used to test this ball.
Ball/min knob (range: 0 to 100) Allows setting of ball frequency from 0 to 100 balls/min. (Can also be
used to start and stop continuous play)
"Place" button Allows selection of one of three BALL PLACEMENT modes: Program, Separate, or
Random
"Ball type" button Allows selection of one of two BALL TYPE modes : Program or Random
(See chapters 4,5, and 6 for more information on using the control panel.)
"AFC" Automatic Frequency Control (see chapter 5)
"Memory Controls” Settings for saving programs. (See memory section)
