11. Technical data
AQA total Mod. 5600 8400 11200 14000
Connection diameter DN [mm] 40 40 50 50
Connection outside-thread [inch] 6/4" 6/4" 2" 2"
Treatment output [l/min] 93 140 187 233
max. simultaneous [m
3
/h] 5,6 8,4 11,2 14
Residential units 5–8 RU 9–16 RU 17–28 RU 29–44 RU
No. of cartridges [amount] 2 3 4 5
Capacity per cartridge [m
3
] 575±25 575±25 575±25 575±25
Treatment capacity total [m
3
] 1150±50 1725±75 2300±100 2875±125
Pressure drop at nominal flow rate [bar] 0,8 0,8 0,8 0,8
Nominal pressure/operating pressure [bar] 2 / 10 2 / 10 2 / 10 2 / 10
Water hardness max. [°dH/ppm] 40/712 40/712 40/712 40/712
Max. water temperature [°C/°F] 30/86 30/86 30/86 30/86
Ambient temperature [°C/°F] 40/104 40/104 40/104 40/104
Max. boiler temperature [°C/°F] 80/176 80/176 80/176 80/176
Unit height total [mm] 1280 1280 1280 1280
Unit width [mm] 560 560 825 825
Operating weight [kg/lb] 57/126 64/141 94/207 101/223
Mains connection [V/Hz] 230/50 230/50 230/50 230/50
Protection class IP 54 IP 54 IP 54 IP 54
Electrical connection output [W] 120 180 240 300
Energy consumption [kWh/m
3
] 0,055 0,055 0,055 0,055
Output in standby operation [Wh] 13 13 15 15
