untag
Discard
Hybrid mode
In
vlan tag
If the VLAN in the message is permit to pass
port, it will be forwarded directly; If the VLAN
in the message doesn’t permit to pass port, it
is discarded.
untag
Add default vlan(native-vlan) for untagged
message and forward.
Out
vlan tag
If the VLAN in the message is permit to pass
port,according vlan tag or vlan untag of
message to discard or no discard vlan
tag,then forward message,If the VLAN ID of
the message is the default (native-VLAN)
VLAN, then the VLAN tag is discard and
forward; If the VLAN in the message doesn’t
permit to pass port, it is discarded.
untag
Discard
5.4.3 Configure OLT PON Port Service Vlan
We can config PON port vlan mode as access,hybrid and trunk,according to our network plan
configure different mode,if message from ONU is untag,we can configure PON port vlan mode is
access or hybrid untag mode;if message from ONU is tag,we can configure PON port vlan mode is
trunk or hybrid tag mode; configure way as follows.
Config PON1 port vlan mode is access:
OLT(config)# interface epon 0/0
OLT(config-interface-epon-0/0)# vlan mode 1 access
OLT(config-interface-epon-0/0)# vlan access 1 100
OLT(config-interface-epon-0/0)# exit
Config PON1 port vlan mode is trunk:（PON port is trunk mode in this document）:
OLT(config)# interface epon 0/0
OLT(config-interface-epon-0/0)# vlan mode 1 trunk
OLT(config-interface-epon-0/0)# vlan trunk 1 100,200,300
OLT(config-interface-epon-0/0)# exit
Config PON1 port vlan mode is hybird:
OLT(config)# interface epon 0/0
OLT(config-interface-epon-0/0)# vlan mode 1 hybrid
OLT(config-interface-epon-0/0)# vlan hybrid 1 tagged 100,200,300
OLT(config-interface-epon-0/0)# exit
