31
Add pon 1 onu 2 successfully.
4.Add all the ONU under PON port:
ont confirm command can be used to add all the ONU under PON port, and also can add ONU
separately.：
OLT(config-interface-epon-0/0)# ont confirm 1 all mac-auth ont-lineprofile-id 1 ont-srvprofile-id 1
6.6 Check ONU Registration Status
After adding ONU, use show ont info command to query the online status of ONU, and ensure that
the ”Control flag” of ont is “Active”, ”Run State” is ”Online”, ”Config state” is “Success” and ”Match
state” is ”Match”.
OLT(config-interface-epon-0/0)# show ont info 1 all
-----------------------------------------------------------------------------
F/S P ONT MAC Control Run Config Match Desc
ID flag state state state
----------------------------------------------------------------------------
0/0 1 1 E0:67:B3:09:F0:21 active online success match
0/0 1 2 E0:67:B3:12:05:3E active online success match
-----------------------------------------------------------------------------
Total: 2, online 2
When the ONU configuration status is failed, ONU cannot up:
 If the “Control flag” is “deactive”,we need to use ont activate command to activate ONU in
EPON mode.
 If the ONU not online, the “Run state” is “offline”, it may be a physical line break, or optical
module is damaged, so we need to check all device and the physical line.
 If the ONU “config state” is “failed”, it means ONU’s configuration is not applicable to some
configuration of srvprofile, we need to capture packet on the ONU and analyze onu not
accept which configuration.
 If the ONU “Match state” is “Mismatch”, it shows that onu srvprofile capability(port number)
don't Match ONU practical capability,we can use show ont capability and show ont config -
capability to contrast ONU practical ability and onu srvprofile capability.
6.7 Configure Bridge ONU（SFU）Service
6.7.1 Configure Bridge ONU(SFU) Internet Service
premise condition of ONU to open internet service:
 OLT connect to uplink device and open internet service
 OLT have created vlan for internet
 OLT have configured GE port vlan
 OLT have configured PON port vlan
 ONU have registered and bind to lineprofile and srvprofile
SFU ethernet port vlan mode have transparent,tag(access),trunk mode and so on,we can
