5.4.4 Configure OLT Multicast Service

Configure IGMP and multicast-vlan 200

OLT(config)# igmp mode snooping

OLT(config)# multicast-vlan 200

OLT(config-multicast-vlan-200)# igmp program add program-index 1 ip 224.3.3.3

OLT(config-multicast-vlan-200)# igmp router-port ge 0/0/6

OLT(config-multicast-vlan-200)# btv

OLT(config-btv)# igmp user add user-index 1 pon 0/0/2 ont 2 vlan 1000 no-auth

OLT(config-btv)# multicast-vlan 200

OLT(config-multicast-vlan-200)# igmp member user-index 1

OLT(config-multicast-vlan-200)# exit

NOTE：

igmp program add program-index command is used to create multicast program table. Only the

program table in the multicast vlan, the user can watch the program. Create multicast program

table can use igmp program add program-index <1-2000> batch command to batch add program

or use igmp program add program-index <1-2000> ip command to add program single.

5.5 Check ONU Register Status.

In OLT discrete mode,ONU is automatically registered,after ONU is automatically registered,use

command show ont info to query ONU online status.make sure ONU “Control flag”is“Active”,“Run

State”is“Online”,“Config state”is“Success”and“Match state”is“Match”

OLT(config-interface-epon-0/0)# show ont info 1 all

-----------------------------------------------------------------------------

F/S P ONT MAC Control Run Config Match Desc

ID flag state state state

----------------------------------------------------------------------------

0/0 1 1 E0:67:B3:09:F0:21 active online success match

0/0 1 2 E0:67:B3:12:05:3E active online success match

----------------------------------------------------------------------------

Total: 2, online 2

5.6 Configure Bridge ONU(SFU) Service

In OLT discrete mode,we need enter OLT to config ONU one by one,config way as follows:

5.6.1 Configure Bridge Onu(SFU) Internet Service

Premise condition of ONU to open internet service:

 OLT connect to uplink device and open internet service
