33
OLT(config-epon-srvprofile-11)# port multicast-vlan eth 1 200
OLT(config-epon-srvprofile-11)# commit
OLT(config-epon-srvprofile-11)# exit
----end
6.8 Gateway ONU（HGU）Service Configure Introduction
Gateway ONU(HGU) can provide internet,voice,iptv service for FTTH,support PPPOE dial-up,
network address translation (NAT), Internet Group Management Protocol (IGMP), due to the ONU
heve route function, so we need configure onu wan and lan in onu web or TR069 server,not need
configure ONU port in OLT, OLT don’t support configure ONU route wan, specific configure way can
refer to the previous discrete configuration method and the ONU user manual.
7 Configure OLT QinQ Service
7.1 Data Plan
Main Data Plan List
Configure Iteam
Data
VLAN
SVLAN 400 : QinQ service outer vlan
CVLAN 100-200:QinQ service inner vlan
OLT Port Configure
Ge8：VLAN 400 Hybrid mode
PON2：VLAN 400 Hybrid mode
Bridge ONT Port Configure
LAN 3：VLAN 100
Gateway ONT Port Configure
LAN 3：VLAN 100
7.2 Configure Processes
