C-Data FD1208S User Manual

Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055)
Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com
3
 parameter for console login software
Baud Rate:9600
Parity Check:None
Databit:8
Stopbit:1
Flow Control:None
Login OLT by console login software,then input username:root,password:admin
[OLT console connection diagram]
[OLT console connection device]
Port on Computer
Required Cable
Port on OLT
Serial Port
RJ-45 to DB-9 Console Cable
RJ-45 Console Port
USB Type-A Port
 USB to RS-232 compatible serial port adapter ( Adapter may
require a software driver )
 RJ-45 to DB-9 Console Cable
2.3 OLT Login By Telnet
There are two way to telnet,one is outband management,another is inband management.
1. Outband management(connect OLT MGMT port)
set PC ip as 192.168.1.X(except 192.168.1.100),PC connect to OLT MGMT port, login the OLT with
