Instruction Booklet5-Series
14
Push down the Tiller Angle Adjustment (Y) to fold the tiller in a lower position. (See Fig. 27)
Once all the parts have been disassembled, you are now able to put the pieces in storage
or in a vehicle for transportation. (See Fig. 28)
Figure 27
Figure 27
Figure 28
Figure 28
(Y)
