4 Conguration
The following information is contained in the top section of the "Status" tab:
Printer type
Firmware version
Bootloader version
Printhead temperature and temperature of CPU
Heat voltage for the printhead.
The heat voltage is only active during printing. Otherwise, 0.0 V is displayed.
Operative time of the printer
Number of labels printed since commissioning
Previously printed paper length with thermal transfer printing
Previously printed paper length with thermal direct printing
Printer status: "Ready", "Printing label", "Settings" or "Error"
Notice!
Information is not updated automatically while the "Status" tab is open. Updating occurs when the tab is
changed or by clicking the "Update" button.
A list of the events which have occurred since the printer was switched on are found in the bottom section of the tab.
No more than the last eight events are displayed.
The "Ready" event provides information on when the printer was switched on.
The buttons on the bottom line of the "Status" tab have the following functions:
Button Function
Display Opens a window which shows the current printer display.
The update interval (in s) can be set on the scale below the display. The display is not updated
automatically with the "0" setting.
Reset Hard : functions like switch-off and switch-on
Soft : functions like the cancel key
Print Opens the window for the settings of a local printer or network printer to be used to print the
contents of the "Status" tab.
Update Updates the display on the "Status" tab.
11 Buttons on the "Status" tabTable
•
•
•
•
•
•
•
•
•
•
•
